Icom IC-718 Service Manual Addendum page 62

Mar. 2010
SECTION 5.
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110004080 S.IC UPC2709T-E3
IC1701 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC1751 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2001 1110004870 S.IC TA4101F (TE12L.F)
IC2101 1110003870 S.IC NJM2058M-TE1-#ZZZB
IC2102 1130005641 S.IC TC4W53F(TE12L,F)
IC2201 1140005281 S.IC UPC5023GS-077-E1-A
IC2301 1110004840 S.IC NJM1496V-TE1-#ZZZB
IC2351 1110002700 S.IC NJM2904M-TE1-#FMZB
IC2701 1110003300 S.IC M5282FP 70CD
IC2702 1110001811 S.IC TA7368FG(5,ER)
IC2801 1130004201 S.IC TC4S66F(TE85R,F)
IC2901 1110003091 IC LA4425A-E
IC3001 1130007700 S.IC BU4094BCF-E2
IC3002 1160000131 S.IC TD62783AFG(5,S,EL)
IC3003 1160000131 S.IC TD62783AFG(5,S,EL)
IC3004 1130007700 S.IC BU4094BCF-E2
IC3005 1160000131 S.IC TD62783AFG(5,S,EL)
IC3006 1130007700 S.IC BU4094BCF-E2
IC3301 1110004310 S.IC M62352GP 75EC
IC3401 1110002031 IC TA7808S(Q)
IC3501 1110001401 S.IC UPC1555G2-E1-A
Q101 1580000620 S.FET 3SK131-T2 MAS
Q102 1580000620 S.FET 3SK131-T2 MAS
Q151 1560001420 S.FET 2SK882-GR T5LICOMF 2241
Q201 1530003151 S.TRA 2SC4673D-TD-E
Q501 1590002310 S.TRA DTC114EE TL
Q502 1560001420 S.FET 2SK882-GR T5LICOMF 2241
Q503 1590002310 S.TRA DTC114EE TL
Q511 1590002310 S.TRA DTC114EE TL
Q701 1590002310 S.TRA DTC114EE TL
Q1001 1510000510 S.TRA 2SA1576A T106R
Q1002 1590002310 S.TRA DTC114EE TL
Q1101 1560000641 S.FET 2SK1740-4/5-TB-E
Q1102 1560000641 S.FET 2SK1740-4/5-TB-E
Q1103 1560000641 S.FET 2SK1740-4/5-TB-E
Q1104 1560000641 S.FET 2SK1740-4/5-TB-E
Q1201 1580000620 S.FET 3SK131-T2 MAS
Q1301 1580000620 S.FET 3SK131-T2 MAS
Q1401 1560000721 S.FET 2SK2171-4-TD-E
Q1402 1560000721 S.FET 2SK2171-4-TD-E
Q1501 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1502 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1503 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1504 1530002060 S.TRA 2SC4081 T106 R
Q1505 1510000510 S.TRA 2SA1576A T106R
Q1506 1590002310 S.TRA DTC114EE TL
Q1507 1530002060 S.TRA 2SC4081 T106 R
Q1508 1530002060 S.TRA 2SC4081 T106 R
Q1509 1590001870 S.TRA DTA114EE TL
Q1601 1530002060 S.TRA 2SC4081 T106 R
Q1602 1560000561 S.FET 2SK882-GR(TE85L,F)
Q1603 1580000620 S.FET 3SK131-T2 MAS
Q1611 1530002060 S.TRA 2SC4081 T106 R
Q1703 1510000510 S.TRA 2SA1576A T106R
Q1705 1590002310 S.TRA DTC114EE TL
Q1706 1590002310 S.TRA DTC114EE TL
Q1801 1590001540 S.TRA UMD6N TR
Q1802 1590001540 S.TRA UMD6N TR
Q1803 1590001540 S.TRA UMD6N TR
Q1805 1530002060 S.TRA 2SC4081 T106 R
Q2302 1590002310 S.TRA DTC114EE TL
Q2381 1530002060 S.TRA 2SC4081 T106 R
Q2383 1590002310 S.TRA DTC114EE TL
Q2384 1590002310 S.TRA DTC114EE TL
Q3101 1590002310 S.TRA DTC114EE TL
Q3601 1540000550 S.TRA 2SD1664 T100Q
Q3701 1590002310 S.TRA DTC114EE TL
Q3702 1590001870 S.TRA DTA114EE TL
Q3801 1590002310 S.TRA DTC114EE TL
Q3802 1590001870 S.TRA DTA114EE TL
Q4601 1540000441 S.TRA 2SD1619T-TD-E
Q4801 1590002310 S.TRA DTC114EE TL
D201 1790000620 S.DIO MA77(TX)
D202 1790000620 S.DIO MA77(TX)
D301 1790000620 S.DIO MA77(TX)
D302 1790000620 S.DIO MA77(TX)
D303 1790000620 S.DIO MA77(TX)
D304 1790000620 S.DIO MA77(TX)
D305 1790000620 S.DIO MA77(TX)
D306 1790000620 S.DIO MA77(TX)
D401 1750000431 S.DIO HSB88WSTR-E
D501 1160000070 S.DIO DAN202K T146
D502 1790001251 S.DIO MA2S1110GL
D503 1160000070 S.DIO DAN202K T146
D601 1160000080 S.DIO DAP202K T146
D602 1160000070 S.DIO DAN202K T146
D603 1160000080 S.DIO DAP202K T146
D604 1160000070 S.DIO DAN202K T146
D605 1160000080 S.DIO DAP202K T146
D606 1160000070 S.DIO DAN202K T146
D607 1160000080 S.DIO DAP202K T146
D608 1160000070 S.DIO DAN202K T146
D701 1750000641 S.DIO 1SV312(TE85L,F)
PARTS LIST
DESCRIPTION
[MAIN UNIT]
REF ORDER
NO. NO.
D801 1750000641 S.DIO 1SV312(TE85L,F)
D802 1750000641 S.DIO 1SV312(TE85L,F)
D803 1790000620 S.DIO MA77(TX)
D804 1790000620 S.DIO MA77(TX)
D805 1790000620 S.DIO MA77(TX)
D806 1790000620 S.DIO MA77(TX)
D807 1790000620 S.DIO MA77(TX)
D808 1790000620 S.DIO MA77(TX)
D809 1790000620 S.DIO MA77(TX)
D810 1790000620 S.DIO MA77(TX)
D811 1790000620 S.DIO MA77(TX)
D812 1790000620 S.DIO MA77(TX)
D813 1790000620 S.DIO MA77(TX)
D814 1790000620 S.DIO MA77(TX)
D815 1790000620 S.DIO MA77(TX)
D816 1790000620 S.DIO MA77(TX)
D901 1790000620 S.DIO MA77(TX)
D902 1790000620 S.DIO MA77(TX)
D903 1790000620 S.DIO MA77(TX)
D904 1790000620 S.DIO MA77(TX)
D1301 1790000620 S.DIO MA77(TX)
D1302 1790000620 S.DIO MA77(TX)
D1501 1790001211 S.DIO 1SS375-TL-E
D1503 1790001251 S.DIO MA2S1110GL
D1510 1790001251 S.DIO MA2S1110GL
D1631 1160000070 S.DIO DAN202K T146
D1632 1790000620 S.DIO MA77(TX)
D1701 1730002451 S.ZEN MAZ8043GHL
D1702 1790000951 S.ZEN MAZ8056GML
D1703 1790001251 S.DIO MA2S1110GL
D1704 1160000080 S.DIO DAP202K T146
D1705 1160000080 S.DIO DAP202K T146
D1706 1790001251 S.DIO MA2S1110GL
D1707 1790001251 S.DIO MA2S1110GL
D1801 1790001211 S.DIO 1SS375-TL-E
D1802 1790001251 S.DIO MA2S1110GL
D1803 1790001211 S.DIO 1SS375-TL-E
D1901 1790001211 S.DIO 1SS375-TL-E
D2101 1790001251 S.DIO MA2S1110GL
D2201 1750000370 S.DIO DA221 TL
D2202 1750000370 S.DIO DA221 TL
D2301 1790001251 S.DIO MA2S1110GL
D2381 1790001211 S.DIO 1SS375-TL-E
D2701 1160000080 S.DIO DAP202K T146
D3001 1160000070 S.DIO DAN202K T146
D3002 1160000070 S.DIO DAN202K T146
D3502 1750000370 S.DIO DA221 TL
D3503 1730002321 S.ZEN MAZ8051GML
D3701 1160000070 S.DIO DAN202K T146
D4220 1790001241 S.DIO MA2S7280GL
D4801 1790001251 S.DIO MA2S1110GL
FI301 2010002470 XTA 64M15B1 64.45500 MHz (FL-315)
FI611 2020000210 CER CFJ455K5 (FL-65)
FI1301 2020001330 CER CFWLA455KHFA-B0 (CFWS455HT)
L1 6200003261 S.COI NLV32T-101J
L2 6200003001 S.COI NLV32T-R22J
L100 6200004790 S.COI MLF1608D R47K-T
L101 6200003001 S.COI NLV32T-R22J
L102 6200003011 S.COI NLV32T-R27J
L103 6200001851 S.COI NLV32T-5R6J
L104 6200003261 S.COI NLV32T-101J
L105 6140003210 S.COI LR-358
L106 6150004270 COI LS-483A (C-14924)
L151 6150004280 COI LS-484B (C-14927)
L152 6200003261 S.COI NLV32T-101J
L153 6200003550 S.COI MLF1608A 4R7K-T
L201 6200001831 S.COI NLV32T-100J
L202 6200003001 S.COI NLV32T-R22J
L301 6150005110 COI LS-540
L302 6150004270 COI LS-483A (C-14924)
L303 6150005110 COI LS-540
L401 6140003210 S.COI LR-358
L402 6140003530 COI LR-395
L501 6150004090 COI LS-469 (C-13969)
L701 6200003261 S.COI NLV32T-101J
L702 6200003261 S.COI NLV32T-101J
L703 6200003261 S.COI NLV32T-101J
L801 6200003261 S.COI NLV32T-101J
L802 6200012670 S.COI LB3218T331K
L811 6200002961 S.COI NLV32T-4R7J
L812 6200003321 S.COI NLV32T-3R3J
L813 6200003261 S.COI NLV32T-101J
L814 6200003261 S.COI NLV32T-101J
L821 6200001851 S.COI NLV32T-5R6J
L822 6200003111 S.COI NLV32T-6R8J
L831 6200003261 S.COI NLV32T-101J
L832 6200003091 S.COI NLV32T-2R7J
L833 6200003101 S.COI NLV32T-3R9J
L835 6200002961 S.COI NLV32T-4R7J
L836 6200001851 S.COI NLV32T-5R6J
L841 6200003261 S.COI NLV32T-101J
L842 6200002991 S.COI NLV32T-2R2J
L843 6200002991 S.COI NLV32T-2R2J
L851 6200003261 S.COI NLV32T-101J
1
DESCRIPTION
S.=Surface mount
