Icom IC-718 Service Manual Addendum page 115

Oct. 2008
[FILTER UNIT]
REF ORDER
NO. NO.
D1 1160000070 S.DIO DAN202K T146
D2 1790000980 S.DIO MA742 (TX)
D3 1790000980 S.DIO MA742 (TX)
L1 6140001990 COL LR-226 (T68-2)
L2 6140002000 COL LR-227 (T68-2)
L3 6140001780 COL LR-214 (T50-2)
L4 6140001790 COL LR-215 (T50-2)
L5 6140001800 COL LR-216 (T50-2)
L6 6140001800 COL LR-216 (T50-2)
L7 6140003500 COL LR-392 (T50-10)
L8 6140003500 COL LR-392 (T50-10)
L9 6110002910 COL LA-480
L10 6110002920 COL LA-481
L11 6110002890 COL LA-478
L12 6110002900 COL LA-479
L13 6140003490 COL LR-391 (TR10X5X5 3A6)
L14 6140002520 COL LR-290 (TR6X3X2 7A3)
L15 6200002041 S.COL NLV25T-101J
L16 6200005051 S.COL NLV25T-330J
L17 6200005051 S.COL NLV25T-330J
L18 6200005051 S.COL NLV25T-330J
L19 6200005051 S.COL NLV25T-330J
L20 6200005011 S.COL NLV25T-100J
L21 6200005011 S.COL NLV25T-100J
L22 6200002041 S.COL NLV25T-101J
L23 6200002041 S.COL NLV25T-101J
L24 6140001810 COL LR-217 (T50-10)
L25 6110001680 COL LA-254
L100 6200005051 S.COL NLV25T-330J
L101 6200005051 S.COL NLV25T-330J
L102 6200005011 S.COL NLV25T-100J
L103 6200005051 S.COL NLV25T-330J
L104 6200005011 S.COL NLV25T-100J
L105 6200005051 S.COL NLV25T-330J
R1 7540000250 ABS SA05C 401N
R2 7030003590 S.RES ERJ3GEYJ 183 V (18 k)
R3 7030008190 S.RES ERJ12YJ330U (33)
R4 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R5 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R6 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R7 7030003400 S.RES ERJ3GEYJ 471 V (470)
R8 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R9 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R20 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
C1 4030008920 S.CER C1608 JB 1H 473K-T
C2 4030008920 S.CER C1608 JB 1H 473K-T
C3 4030008920 S.CER C1608 JB 1H 473K-T
C4 4030008920 S.CER C1608 JB 1H 473K-T
C5 4030008920 S.CER C1608 JB 1H 473K-T
C6 4030008920 S.CER C1608 JB 1H 473K-T
C7 4030008920 S.CER C1608 JB 1H 473K-T
C8 4030008920 S.CER C1608 JB 1H 473K-T
C9 4030006880 S.CER C1608 JB 1H 472K-T
C10 4030006880 S.CER C1608 JB 1H 472K-T
C11 4030006880 S.CER C1608 JB 1H 472K-T
C12 4030006880 S.CER C1608 JB 1H 472K-T
C13 4030006880 S.CER C1608 JB 1H 472K-T
C14 4030007130 S.CER C1608 CH 1H 101J-T
C15 4030007010 S.CER C1608 CH 1H 100D-T
C16 4030007130 S.CER C1608 CH 1H 101J-T
C17 4610001340 TRI ECR-LA010 A12
C18 4030007160 S.CER C1608 CH 1H 181J-T
C19 4030006870 S.CER C1608 JB 1H 222K-T
C20 4030011340 S.CER C1608 CH 1H 471J-T
C21 4030011340 S.CER C1608 CH 1H 471J-T
C22 4010007510 CER HM17SJ SL 821J 500V
C23 4010005880 CER HM95SJ SL 271J 500V
C24 4010005880 CER HM95SJ SL 271J 500V
C25 4010007510 CER HM17SJ SL 821J 500V
C26 4030012480 S.CER GRM31M2C2H121JV01L (GRM42-6 CH)
C27 4010007510 CER HM17SJ SL 821J 500V
C28 4010005870 CER HM95SJ SL 221J 500V
C29 4010005850 CER HM95SJ SL 181J 500V
C30 4010005360 CER HM11SJ SL 301J 500V
C31 4010005870 CER HM95SJ SL 221J 500V
C32 4010005930 CER HM11SJ SL 391J 500V
C33 4010005750 CER HM60SJ SL 680J 500V
C34 4010005870 CER HM95SJ SL 221J 500V
C35 4010005870 CER HM95SJ SL 221J 500V
C36 4010005870 CER HM95SJ SL 221J 500V
C37 4010005360 CER HM11SJ SL 301J 500V
C38 4030011550 S.CER GRM31M2C2H680JV01L (GRM42-6 CH)
C39 4010005780 CER HM60SJ SL 101J 500V
C40 4010005370 CER HM11SJ SL 331J 500V
C41 4010005370 CER HM11SJ SL 331J 500V
C43 4010005760 CER HM60SJ SL 750J 500V
C44 4010005880 CER HM95SJ SL 271J 500V
C45 4010005820 CER HM74SJ SL 121J 500V
C46 4010005860 CER HM95SJ SL 201J 500V
C47 4010005780 CER HM60SJ SL 101J 500V
C48 4030014460 S.CER GRM31M2C2H820JV01L (GRM42-6 CH)
C49 4010005830 CER HM74SJ SL 151J 500V
C50 4030011180 S.CER GRM31M2C2H220JV01L (GRM42-6 CH)
C51 4030014460 S.CER GRM31M2C2H820JV01L (GRM42-6 CH)
C52 4030011550 S.CER GRM31M2C2H680JV01L (GRM42-6 CH)
C53 4010005730 CER HM60SJ SL 470J 500V
C54 4010005850 CER HM95SJ SL 181J 500V
C55 4030011240 S.CER GRM31M2C2H470JV01L (GRM42-6 CH)
DESCRIPTION
[FILTER UNIT]
REF ORDER
NO. NO.
C56 4010005770 CER HM60SJ SL 820J 500V
C58 4030011240 S.CER GRM31M2C2H470JV01L (GRM42-6 CH)
C60 4010005620 CER HM60SJ SL 120J 500V
C61 4030014460 S.CER GRM31M2C2H820JV01L (GRM42-6 CH)
C63 4030006870 S.CER C1608 JB 1H 222K-T
C64 4010007590 CER HM15SJ SL 681J 500V
C65 4010007590 CER HM15SJ SL 681J 500V
C66 4010007590 CER HM15SJ SL 681J 500V
C67 4010007590 CER HM15SJ SL 681J 500V
C68 4010005930 CER HM11SJ SL 391J 500V
C69 4010005930 CER HM11SJ SL 391J 500V
C70 4030006880 S.CER C1608 JB 1H 472K-T
C71 4030006880 S.CER C1608 JB 1H 472K-T
C72 4030006880 S.CER C1608 JB 1H 472K-T
C73 4030006880 S.CER C1608 JB 1H 472K-T
C74 4030006880 S.CER C1608 JB 1H 472K-T
C75 4030006880 S.CER C1608 JB 1H 472K-T
C76 4030006880 S.CER C1608 JB 1H 472K-T
C78 4030011730 S.CER GRM31M2C2H101JV01L (GRM42-6 CH)
C80 4010005930 CER HM11SJ SL 391J 500V
C81 4010005930 CER HM11SJ SL 391J 500V
C101 4010005430 CER HM60SJ CH 050C 500V
C103 4030011090 S.CER GRM31M2C2H7R0DV01L (GRM42-6 CH)
C104 4030011550 S.CER GRM31M2C2H680JV01L (GRM42-6 CH)
C107 4030011170 S.CER GRM31M2C2H180JV01L (GRM42-6 CH)
C108 4030011510 S.CER GRM31M2C2H560JV01L (GRM42-6 CH)
C110 4030011090 S.CER GRM31M2C2H7R0DV01L (GRM42-6 CH)
RL1 6330001471 RLY AJS1311F-K2
RL2 6330001471 RLY AJS1311F-K2
RL3 6330001471 RLY AJS1311F-K2
RL4 6330001471 RLY AJS1311F-K2
RL5 6330001471 RLY AJS1311F-K2
RL6 6330001471 RLY AJS1311F-K2
RL7 6330001471 RLY AJS1311F-K2
RL8 6330001471 RLY AJS1311F-K2
RL9 6330001471 RLY AJS1311F-K2
RL10 6330001471 RLY AJS1311F-K2
RL11 6330001471 RLY AJS1311F-K2
RL12 6330001471 RLY AJS1311F-K2
RL13 6330001330 RLY AG 201344
J1 6510022631 CNR 10FMN-BTRK-A (LF) (SN)
J2 6510007020 CNR TMP-J01X-V6
J3 6510007020 CNR TMP-J01X-V6
J4 6910001040 CNR IPS-1136
J5 6910001040 CNR IPS-1136
W2 9001502002 WIR 72/98/030/X98/X98
W3 6910001031 JMP IPS-1041-4-PT
W4 6910001031 JMP IPS-1041-4-PT
W5 7030008240 S.RES ERJ12Y0R00U
W72 7030003860 S.RES ERJ3GE JPW V
W73 7030003860 S.RES ERJ3GE JPW V
[VR UNIT]
REF ORDER
NO. NO.
R1 7210003040 VAR TP96D26-22F-10KBX2-2240
R2 7210003030 VAR TP96D00-22F-10KBX2-2240
R4 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k)
J1 6510022051 S.CNR 10FM-1.0SP-1.9-TF (LF) (SN)
[MIC UNIT]
REF ORDER
NO. NO.
J1 6510000191 CNR FM214-8SS (P) -1
J2 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN)
[PHONE UNIT]
REF ORDER
NO. NO.
L1 6200003950 S.COL HF50ACC 322513-T
R1 7030006070 S.RES ERJ12YJ101U (100)
R2 7030006070 S.RES ERJ12YJ101U (100)
R3 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
J1 6450001250 CNR HLJ4306-01-3070
J2 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
11
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
S.=Surface mount
