Icom IC-718 Service Manual Addendum page 126

[LOGIC UNIT]
REF ORDER
NO. NO.
R146 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R147 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R148 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R149 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R150 7030003360 S.RES ERJ3GEYJ 221 V (220)
R151 7030003360 S.RES ERJ3GEYJ 221 V (220)
R153 7030003360 S.RES ERJ3GEYJ 221 V (220)
R154 7030003360 S.RES ERJ3GEYJ 221 V (220)
R156 7030003360 S.RES ERJ3GEYJ 221 V (220)
R158 7030003360 S.RES ERJ3GEYJ 221 V (220)
R160 7030003360 S.RES ERJ3GEYJ 221 V (220)
R161 7030003360 S.RES ERJ3GEYJ 221 V (220)
R162 7030003360 S.RES ERJ3GEYJ 221 V (220)
R163 7030003360 S.RES ERJ3GEYJ 221 V (220)
R164 7030003360 S.RES ERJ3GEYJ 221 V (220)
R165 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R166 7030003360 S.RES ERJ3GEYJ 221 V (220)
R169 7030003360 S.RES ERJ3GEYJ 221 V (220)
R171 7030003360 S.RES ERJ3GEYJ 221 V (220)
R172 7030003360 S.RES ERJ3GEYJ 221 V (220)
R173 7030003360 S.RES ERJ3GEYJ 221 V (220)
R174 7030003360 S.RES ERJ3GEYJ 221 V (220)
R175 7030003360 S.RES ERJ3GEYJ 221 V (220)
R176 7030003360 S.RES ERJ3GEYJ 221 V (220)
R177 7030003360 S.RES ERJ3GEYJ 221 V (220)
R179 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R180 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R182 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R185 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R186 7030003360 S.RES ERJ3GEYJ 221 V (220)
R188 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R190 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R191 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R193 7030003360 S.RES ERJ3GEYJ 221 V (220)
R195 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R196 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R197 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R198 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R199 7030003430 S.RES ERJ3GEYJ 821 V (820)
R201 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R211 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R212 7030003360 S.RES ERJ3GEYJ 221 V (220)
C1 4030007030 S.CER C1608 CH 1H 150J-T
C2 4030007030 S.CER C1608 CH 1H 150J-T
C3 4030006900 S.CER C1608 JB 1H 103K-T
C4 4030011600 S.CER C1608 JB 1E 104K-T
C5 4510008540 S.ELE EEE1CA100SR
C6 4030011600 S.CER C1608 JB 1E 104K-T
C7 4510008550 S.ELE EEE1HA010SR
C8 4030011600 S.CER C1608 JB 1E 104K-T
C9 4030006900 S.CER C1608 JB 1H 103K-T
C11 4030011600 S.CER C1608 JB 1E 104K-T
C12 4510008540 S.ELE EEE1CA100SR
C13 4510008540 S.ELE EEE1CA100SR
C14 4030011600 S.CER C1608 JB 1E 104K-T
C15 4030011600 S.CER C1608 JB 1E 104K-T
C16 4510008540 S.ELE EEE1CA100SR
C17 4510008540 S.ELE EEE1CA100SR
C18 4030011600 S.CER C1608 JB 1E 104K-T
C19 4510008540 S.ELE EEE1CA100SR
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030007130 S.CER C1608 CH 1H 101J-T
C41 4030007130 S.CER C1608 CH 1H 101J-T
C42 4030006880 S.CER C1608 JB 1H 472K-T
C43 4030006880 S.CER C1608 JB 1H 472K-T
C44 4030006880 S.CER C1608 JB 1H 472K-T
C45 4030006880 S.CER C1608 JB 1H 472K-T
C46 4030006880 S.CER C1608 JB 1H 472K-T
C47 4030006880 S.CER C1608 JB 1H 472K-T
C101 4030011600 S.CER C1608 JB 1E 104K-T
C102 4030006860 S.CER C1608 JB 1H 102K-T
C103 4030009110 S.CER C3216 JB 1C 474K-T
C111 4030011600 S.CER C1608 JB 1E 104K-T
C112 4030011600 S.CER C1608 JB 1E 104K-T
C113 4030011600 S.CER C1608 JB 1E 104K-T
C114 4030011600 S.CER C1608 JB 1E 104K-T
J1 6510020421 S.CNR S4B-PH-SM4-TB (LF) (SN)
J3 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN)
J4 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN)
J5 6510022621 S.CNR 10FMN-BMTTR-A-TBT (LF) (SN)
J6 6510021721 S.CNR 30FLT-SM2-TB (LF) (SN)
J7 6510021721 S.CNR 30FLT-SM2-TB (LF) (SN)
J9 6510022611 S.CNR 16FMN-BMTTR-A-TBT (LF) (SN)
DS1 5030002490 LCD A0087A LCD
DS70 5040002940 S.LED TLYU1002A (T02)
DS71 5040002940 S.LED TLYU1002A (T02)
DS72 5040002940 S.LED TLYU1002A (T02)
DS73 5040002940 S.LED TLYU1002A (T02)
DS74 5040002940 S.LED TLYU1002A (T02)
DS75 5040002940 S.LED TLYU1002A (T02)
DS76 5040002940 S.LED TLYU1002A (T02)
DS77 5040002940 S.LED TLYU1002A (T02)
DS78 5040002940 S.LED TLYU1002A (T02)
DS79 5040002940 S.LED TLYU1002A (T02)
DS80 5040002940 S.LED TLYU1002A (T02)
DS81 5040002940 S.LED TLYU1002A (T02)
DESCRIPTION
[LOGIC UNIT]
REF ORDER
NO. NO.
DS82 5040002940 S.LED TLYU1002A (T02)
DS83 5040002940 S.LED TLYU1002A (T02)
DS84 5040002940 S.LED TLYU1002A (T02)
DS85 5040002940 S.LED TLYU1002A (T02)
DS86 5040002940 S.LED TLYU1002A (T02)
DS87 5040002940 S.LED TLYU1002A (T02)
DS88 5040002940 S.LED TLYU1002A (T02)
DS89 5040002940 S.LED TLYU1002A (T02)
DS90 5040002940 S.LED TLYU1002A (T02)
W1 7030003860 S.RES ERJ3GE JPW V
W70 7030003860 S.RES ERJ3GE JPW V
W101 7030003860 S.RES ERJ3GE JPW V
W102 7030003860 S.RES ERJ3GE JPW V
EP2 6910012350 S.BEA MMZ1608Y 102BT
EP40 6910012350 S.BEA MMZ1608Y 102BT
EP45 6910012350 S.BEA MMZ1608Y 102BT
EP46 6910012350 S.BEA MMZ1608Y 102BT
EP70 8930051450 LCT SRCN-2241-SP-N-W
EP152 6910012350 S.BEA MMZ1608Y 102BT
EP155 6910012350 S.BEA MMZ1608Y 102BT
EP157 6910012350 S.BEA MMZ1608Y 102BT
EP159 6910012350 S.BEA MMZ1608Y 102BT
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
3
DESCRIPTION
S.=Surface mount
