Icom IC-718 Service Manual Addendum page 134

[PA UNIT]
REF ORDER
NO. NO.
IC1 1180001251 S.IC TA7808F (TE16L,Q)
Q1 1560001241 S.FET RD01MUS1-T113
Q2 1560001530 FET RD15HVF1-101
Q3 1560001530 FET RD15HVF1-101
Q4 1560001391 FET RD70HHF1-101
Q5 1560001391 FET RD70HHF1-101
Q7 1590003280 S.TR UNR9211J-(TX)
D4 1790000700 DIO DSA3A1
D5 1790000700 DIO DSA3A1
D6 1160000050 S.DIO DAP202U T106
D7 1730000481 S.ZEN RD10M-T2B-A B3
D8 1160000060 S.DIO DAN202U T106
D9 1160000060 S.DIO DAN202U T106
D10 1160000060 S.DIO DAN202U T106
D11 1160000060 S.DIO DAN202U T106
L1 6140002350 COL LR-274 (RIB4X7X5 3A6)
L2 6140002980 COL LR-143 <KN>
L3 6140003600 COL LR-401 <KN>
L4 6140003590 COL LR-400 (TR10X5X5 6H3)
L5 6140004570 COL LR-507
L24 6200003241 S.COL NLV32T-221J
L25 6200003241 S.COL NLV32T-221J
L28 6140003440 COL LR-386 (FK-100E-5003H)
L29 6140003440 COL LR-386 (FK-100E-5003H)
R1 7030003310 S.RES ERJ3GEYJ 820 V (82)
R2 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
R3 7030003400 S.RES ERJ3GEYJ 471 V (470)
R4 7030006210 S.RES ERJ12YJ4R7U (4.7)
R5 7030006240 S.RES ERJ12YJ181U (180)
R6 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k)
R7 7030000220 S.RES MCR10EZHJ 47 (470)
R8 7030000220 S.RES MCR10EZHJ 47 (470)
R9 7030011300 S.RES ERJ1TY 331U (330)
R10 7030011300 S.RES ERJ1TY 331U (330)
R11 7030003230 S.RES ERJ3GEYJ 180 V (18)
R12 7030003370 S.RES ERJ3GEYJ 271 V (270)
R13 7030003370 S.RES ERJ3GEYJ 271 V (270)
R15 7030010540 S.RES ERJ1TYJ 330U (33)
R16 7030010540 S.RES ERJ1TYJ 330U (33)
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R18 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R19 7030010570 S.RES ERJ1TYJ 4R7U (4.7)
R20 7030000010 S.RES MCR10EZHJ JPW (000)
R22 7030010950 S.RES ERJ1TYJ 100U (10)
R26 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R27 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R28 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7)
R29 7030003420 S.RES ERJ3GEYJ 681 V (680)
R31 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k)
R32 7030010570 S.RES ERJ1TYJ 4R7U (4.7)
R33 7030010570 S.RES ERJ1TYJ 4R7U (4.7)
R34 7030010540 S.RES ERJ1TYJ 330U (33)
R36 7030010540 S.RES ERJ1TYJ 330U (33)
R37 7030010410 S.RES ERJ1TYJ 220U (22)
R38 7030010410 S.RES ERJ1TYJ 220U (22)
R39 7030011240 S.RES LRF3W-LF-01-R020F
R40 7030011240 S.RES LRF3W-LF-01-R020F
R46 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
R47 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k)
R49 7030007630 S.RES MCR100JZHJ 0.68 (R68)
R50 7510001360 S.TMR NTCG20 3SH 333JT
R51 7310005240 TRI VM5CK-PVB 5 k
R52 7030003860 S.RES ERJ3GE JPW V
R53 7030003860 S.RES ERJ3GE JPW V
R54 7030003860 S.RES ERJ3GE JPW V
R55 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R56 7310005240 TRI VM5CK-PVB 5 k
R57 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R58 7310005240 TRI VM5CK-PVB 5 k
R60 7030007630 S.RES MCR100JZHJ 0.68 (R68)
R61 7030003360 S.RES ERJ3GEYJ 221 V (220)
R62 7310005200 TRI VM5CK-PVB 2 k
R63 7030003360 S.RES ERJ3GEYJ 221 V (220)
R64 7310005200 TRI VM5CK-PVB 2 k
C1 4030017320 S.CER GRM21BB11H104KA01L (GRM40-034)
C2 4030004720 S.CER C2012 JB 1H 102K-T
C3 4030004720 S.CER C2012 JB 1H 102K-T
C4 4030008920 S.CER C1608 JB 1H 473K-T
C5 4030017190 S.CER GRM31AR32J471KW01D
C6 4030017190 S.CER GRM31AR32J471KW01D
C15 4320000270 DMI DM20C 102J5 .
C17 4030008920 S.CER C1608 JB 1H 473K-T
C19 4030008920 S.CER C1608 JB 1H 473K-T
C21 4030005110 S.CER C2012 JB 1E 473K-T
C22 4030006860 S.CER C1608 JB 1H 102K-T
C27 4510004601 ELE 16 ME 1000 HC
C28 4030006880 S.CER C1608 JB 1H 472K-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C30 4030007170 S.CER C1608 CH 1H 221J-T
C31 4030005110 S.CER C2012 JB 1E 473K-T
C32 4510004601 ELE 16 ME 1000 HC
C33 4030006880 S.CER C1608 JB 1H 472K-T
DESCRIPTION
[EUR], [ITA], [FRA], [ESP], [DEN] only
[EUR], [ITA], [FRA], [ESP], [DEN] only
[PA UNIT]
REF ORDER
NO. NO.
C34 4030007170 S.CER C1608 CH 1H 221J-T
C35 4030018980 S.CER C1608 JB 1H 104K-T
C42 4510004601 ELE
C45 4030006880 S.CER C1608 JB 1H 472K-T
C46 4030006880 S.CER C1608 JB 1H 472K-T
C47 4030006880 S.CER C1608 JB 1H 472K-T
C52 4030008920 S.CER C1608 JB 1H 473K-T
C53 4030008920 S.CER C1608 JB 1H 473K-T
C54 4030008920 S.CER C1608 JB 1H 473K-T
C55 4030006880 S.CER C1608 JB 1H 472K-T
C56 4030006880 S.CER C1608 JB 1H 472K-T
C57 4030006880 S.CER C1608 JB 1H 472K-T
C59 4510008500 S.ELE
C60 4030004740 S.CER C2012 JB 1H 472K-T
C61 4030004740 S.CER C2012 JB 1H 472K-T
C62 4030018980 S.CER C1608 JB 1H 104K-T
C63 4510008520 S.ELE
C64 4030018750 S.CER C3225 CH 2J 682K-T
C65 4030018750 S.CER C3225 CH 2J 682K-T
C68 4030011740 S.CER GRM32N2C2H201JV01L (GRM42-2 CH)
C69 4030011740 S.CER GRM32N2C2H201JV01L (GRM42-2 CH)
C70 4030005050 S.CER C2012 CH 1H 331J-T
C72 4030011240 S.CER GRM31M2C2H470JV01L (GRM42-6 CH)
C73 4030018750 S.CER C3225 CH 2J 682K-T
C74 4030018750 S.CER C3225 CH 2J 682K-T
C75 4030011740 S.CER GRM32N2C2H201JV01L (GRM42-2 CH)
C77 4030006880 S.CER C1608 JB 1H 472K-T
C78 4030006880 S.CER C1608 JB 1H 472K-T
C79 4030006880 S.CER C1608 JB 1H 472K-T
C80 4030006880 S.CER C1608 JB 1H 472K-T
C81 4030017320 S.CER GRM21BB11H104KA01L (GRM40-034)
C82 4030017320 S.CER GRM21BB11H104KA01L (GRM40-034)
C83 4030008920 S.CER C1608 JB 1H 473K-T
C84 4030008920 S.CER C1608 JB 1H 473K-T
C85 4030008920 S.CER C1608 JB 1H 473K-T
C86 4030008920 S.CER C1608 JB 1H 473K-T
C87 4030011600 S.CER C1608 JB 1E 104K-T
C94 4030011600 S.CER C1608 JB 1E 104K-T
C103 4510008520 S.ELE
C104 4030011600 S.CER C1608 JB 1E 104K-T
C105 4030011600 S.CER C1608 JB 1E 104K-T
C111 4030011740 S.CER GRM32N2C2H201JV01L (GRM42-2 CH)
C112 4030011740 S.CER GRM32N2C2H201JV01L (GRM42-2 CH)
C113 4320000270 DMI
RL1 6330001600 RLY
J3 6510022611 S.CNR 16FMN-BMTTR-A-TBT (LF) (SN)
J6 6510007020 CNR
J7 6510007020 CNR
F1 5210000131 FUS
F2 5220000230 HOL
F3 5220000230 HOL
EP1 6910019200 S.BEA
EP2 6910019200 S.BEA
EP6 6910012350 S.BEA
EP8 6910019200 S.BEA
EP11 6910012350 S.BEA
EP14 6910012350 S.BEA
EP21 6910012350 S.BEA
EP26 6910018930 S.BEA
EP27 6910018930 S.BEA
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
11
DESCRIPTION
[FRA], [DEN] only
16 ME 1000 HC
EEE1CA101WP [FRA], [DEN] only
[EUR], [FRA], [ESP], [DEN] only
[EUR], [FRA], [ESP], [DEN] only
[FRA], [DEN] only
EEE1CA470SP [FRA], [DEN] only
EEE1CA470SP
DM20C 102J5
ALD 112
TMP-J01X-V6
TMP-J01X-V6
FGB 4A PBF (FGB0 125V)
S-N5054
S-N5054
N2012ZPS121T50
N2012ZPS121T50
MMZ1608Y 102BT
N2012ZPS121T50
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MPZ2012S601A
MPZ2012S601A
S.=Surface mount
