Icom IC-718 Service Manual Addendum page 113

Oct. 2008
[PLL UNIT]
REF ORDER
NO. NO.
R94 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R95 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R96 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R97 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R98 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R99 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R102 7030006080 S.RES ERJ1WYJ220U (22)
R103 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R104 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R105 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R106 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R107 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R108 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R116 7030003320 S.RES ERJ3GEYJ 101 V (100)
R117 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R118 7030003280 S.RES ERJ3GEYJ 470 V (47)
R119 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R120 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R121 7030003360 S.RES ERJ3GEYJ 221 V (220)
R127 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R156 7030003350 S.RES ERJ3GEYJ 181 V (180)
R158 7030003320 S.RES ERJ3GEYJ 101 V (100)
R159 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R160 7030003560 S.RES ERJ3GEYJ 103 V (10 k)
R161 7030003360 S.RES ERJ3GEYJ 221 V (220)
R162 7030003430 S.RES ERJ3GEYJ 821 V (820)
R164 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R165 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R166 7030003800 S.RES ERJ3GEYJ 105 V (1 M)
R169 7030003260 S.RES ERJ3GEYJ 330 V (33)
R171 7030003350 S.RES ERJ3GEYJ 181 V (180)
R172 7030003350 S.RES ERJ3GEYJ 181 V (180)
R180 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k)
R181 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R182 7030003620 S.RES ERJ3GEYJ 333 V (33 k)
R183 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R191 7030003350 S.RES ERJ3GEYJ 181 V (180)
R192 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
C1 4510008500 S.ELE EEE1CA101WP
C2 4550006080 S.TAN TEESVB2 1C 106M8R
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4550006080 S.TAN TEESVB2 1C 106M8R
C5 4510008880 S.ELE EEE1VA330WP
C6 4510008540 S.ELE EEE1CA100SR
C7 4030011600 S.CER C1608 JB 1E 104K-T
C8 4510008540 S.ELE EEE1CA100SR
C9 4510008540 S.ELE EEE1CA100SR
C10 4030011600 S.CER C1608 JB 1E 104K-T
C12 4030006880 S.CER C1608 JB 1H 472K-T
C13 4030006880 S.CER C1608 JB 1H 472K-T
C14 4030007150 S.CER C1608 CH 1H 151J-T
C15 4030008330 S.CER C1608 UJ 1H 560J-T
C16 4610002200 S.TRI TZB4R200EB10R00
C17 4030006880 S.CER C1608 JB 1H 472K-T
C18 4030007130 S.CER C1608 CH 1H 101J-T
C19 4030006880 S.CER C1608 JB 1H 472K-T
C20 4030007030 S.CER C1608 CH 1H 150J-T
C21 4510008500 S.ELE EEE1CA101WP
C22 4030006880 S.CER C1608 JB 1H 472K-T
C23 4030009500 S.CER C1608 CH 1H 0R5B-T
C24 4030007030 S.CER C1608 CH 1H 150J-T
C25 4030018700 S.CER GRM1882P1H121JZ01D
C26 4030007130 S.CER C1608 CH 1H 101J-T
C27 4030006880 S.CER C1608 JB 1H 472K-T
C28 4030006880 S.CER C1608 JB 1H 472K-T
C29 4030006880 S.CER C1608 JB 1H 472K-T
C30 4030006880 S.CER C1608 JB 1H 472K-T
C31 4030006880 S.CER C1608 JB 1H 472K-T
C32 4030006880 S.CER C1608 JB 1H 472K-T
C33 4510008500 S.ELE EEE1CA101WP
C34 4030006880 S.CER C1608 JB 1H 472K-T
C50 4030007050 S.CER C1608 CH 1H 220J-T
C51 4030006930 S.CER C1608 CH 1H 020C-T
C52 4030007060 S.CER C1608 CH 1H 270J-T
C53 4030009500 S.CER C1608 CH 1H 0R5B-T
C54 4030007050 S.CER C1608 CH 1H 220J-T
C55 4030006880 S.CER C1608 JB 1H 472K-T
C62 4030007130 S.CER C1608 CH 1H 101J-T
C63 4030006880 S.CER C1608 JB 1H 472K-T
C64 4030006880 S.CER C1608 JB 1H 472K-T
C65 4030006920 S.CER C1608 CH 1H 010C-T
C66 4030006880 S.CER C1608 JB 1H 472K-T
C67 4030007130 S.CER C1608 CH 1H 101J-T
C68 4030006860 S.CER C1608 JB 1H 102K-T
C103 4030006880 S.CER C1608 JB 1H 472K-T
C104 4030006880 S.CER C1608 JB 1H 472K-T
C106 4030006880 S.CER C1608 JB 1H 472K-T
C108 4030006880 S.CER C1608 JB 1H 472K-T
C109 4030006880 S.CER C1608 JB 1H 472K-T
C111 4030006860 S.CER C1608 JB 1H 102K-T
C112 4030007100 S.CER C1608 CH 1H 560J-T
C114 4030007080 S.CER C1608 CH 1H 390J-T
C115 4030009650 S.CER C1608 CH 1H 240J-T
C116 4030006990 S.CER C1608 CH 1H 080D-T
C117 4030007070 S.CER C1608 CH 1H 330J-T
C118 4030006880 S.CER C1608 JB 1H 472K-T
C119 4030006860 S.CER C1608 JB 1H 102K-T
C120 4030006880 S.CER C1608 JB 1H 472K-T
C126 4030006880 S.CER C1608 JB 1H 472K-T
C127 4030006860 S.CER C1608 JB 1H 102K-T
C128 4030006880 S.CER C1608 JB 1H 472K-T
C129 4030006880 S.CER C1608 JB 1H 472K-T
DESCRIPTION
[PLL UNIT]
REF ORDER
NO. NO.
C130 4030006860 S.CER C1608 JB 1H 102K-T
C132 4030007130 S.CER C1608 CH 1H 101J-T
C134 4030007100 S.CER C1608 CH 1H 560J-T
C135 4030006950 S.CER C1608 CH 1H 040C-T
C136 4030007020 S.CER C1608 CH 1H 120J-T
C137 4030007110 S.CER C1608 CH 1H 680J-T
C138 4030007100 S.CER C1608 CH 1H 560J-T
C139 4030006880 S.CER C1608 JB 1H 472K-T
C141 4030006880 S.CER C1608 JB 1H 472K-T
C143 4030006880 S.CER C1608 JB 1H 472K-T
C144 4030006880 S.CER C1608 JB 1H 472K-T
C145 4030006880 S.CER C1608 JB 1H 472K-T
C146 4030006880 S.CER C1608 JB 1H 472K-T
C147 4030006880 S.CER C1608 JB 1H 472K-T
C148 4030006880 S.CER C1608 JB 1H 472K-T
C149 4030006880 S.CER C1608 JB 1H 472K-T
C150 4030006880 S.CER C1608 JB 1H 472K-T
C151 4030006880 S.CER C1608 JB 1H 472K-T
C152 4030006880 S.CER C1608 JB 1H 472K-T
C153 4030006880 S.CER C1608 JB 1H 472K-T
C155 4030006880 S.CER C1608 JB 1H 472K-T
C156 4030007050 S.CER C1608 CH 1H 220J-T
C157 4030007080 S.CER C1608 CH 1H 390J-T
C158 4030006860 S.CER C1608 JB 1H 102K-T
C159 4030006860 S.CER C1608 JB 1H 102K-T
C160 4030006880 S.CER C1608 JB 1H 472K-T
C161 4030008920 S.CER C1608 JB 1H 473K-T
C165 4610001850 S.TRI TZB4R200AB10R00
C166 4550000460 S.TAN TEESVA 1C 105M8R
C167 4030006880 S.CER C1608 JB 1H 472K-T
C168 4030008920 S.CER C1608 JB 1H 473K-T
C170 4030006880 S.CER C1608 JB 1H 472K-T
C172 4030007060 S.CER C1608 CH 1H 270J-T
C174 4030008920 S.CER C1608 JB 1H 473K-T
C188 4030011600 S.CER C1608 JB 1E 104K-T
C191 4030006880 S.CER C1608 JB 1H 472K-T
C192 4030006880 S.CER C1608 JB 1H 472K-T
C194 4030011340 S.CER C1608 CH 1H 471J-T
C195 4030011340 S.CER C1608 CH 1H 471J-T
C203 4030006880 S.CER C1608 JB 1H 472K-T
C222 4030006880 S.CER C1608 JB 1H 472K-T
C223 4030011600 S.CER C1608 JB 1E 104K-T
C224 4030011600 S.CER C1608 JB 1E 104K-T
C225 4030006940 S.CER C1608 CH 1H 030C-T
C226 4030006940 S.CER C1608 CH 1H 030C-T
C227 4030007100 S.CER C1608 CH 1H 560J-T
C228 4550002890 S.TAN TEESVA 1A 225M8R
J1 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN)
J3 6510022611 S.CNR 16FMN-BMTTR-A-TBT (LF) (SN)
J4 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN)
W1 7030003860 S.RES ERJ3GE JPW V
W7 7030003860 S.RES ERJ3GE JPW V
W9 7030003860 S.RES ERJ3GE JPW V
W10 7030003860 S.RES ERJ3GE JPW V
W92 7030003860 S.RES ERJ3GE JPW V
W170 7030003860 S.RES ERJ3GE JPW V
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
9
DESCRIPTION
S.=Surface mount
