Instruction Manual
Version 1.2
Elation Professional
4295 Charter Street
Los Angels CA 90058
e-mail:
info@elationlighting.com
Web site:
www.elationlighting.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Patend Light 1200 HMI and is the answer not in the manual?

Questions and answers

Summary of Contents for Elation Patend Light 1200 HMI

  • Page 1 Instruction Manual Version 1.2 Elation Professional 4295 Charter Street Los Angels CA 90058 e-mail: info@elationlighting.com Web site: www.elationlighting.com...
  • Page 2 (V1.2)
  • Page 3: Table Of Contents

    Contents Introduction...........................5 1.1 Safety Rules........................7 Installation ..........................8 2.1 Mounting.........................8 2.1.1 Clamps (Hooks)....................8 2.1.2 Mountingplate (optional).................8 2.2 Securing ........................8 2.3 Connectors ........................9 2.3.1 AC Connectors ....................9 2.3.2 DMX ........................9 2.4 Fuses..........................9 The Menu Field ........................10 3.1 DMX- Channel Addresssing ..................10 3.2 Read outs of Lamp and Unit Running Time .............11 3.2.1 Lamp Time 1....................11 3.2.2 Lamp Time 2....................11...
  • Page 4 Gobo Replacement ......................18 6.1 Safety Rules.........................18 6.2 How to Replace the Gobos..................18 Maintenance........................20 7.1 Mirror and Optical System ..................20 7.1.1 Cleaning the inside Mirror and the outside Optical System ....20 7.1.2 Cleaning the outside Optical System............21 7.2 Ventilation System......................22 Technical Data /Overview....................23 (V1.2)
  • Page 5: Introduction

    Introduction Illustration 1-1 (V1.2)
  • Page 6 Illustration 1-2 (V1.2)
  • Page 7: Safety Rules

    1.1 Safety Rules 0 is a High-Tech Product. To guarantee smooth operation, it is necessary to follow all safety rules. 1. Make sure that Head and Mirror of the 0 , can rotate without any mechanical problems and that all fan openings are clean and not blocked by anything.
  • Page 8: Installation

    Installation 2.1 Mounting To mount the 0 use the 8 threads M12 at the backside of the system or use the slide nuts at the side of the body. 2.1.1 Clamps (Hooks) Mount clamps and/or hooks directly to the base plate. Please make sure to use right sized clamps and hooks and fit them securely.
  • Page 9: Connectors

    Connectors 2.3.1 AC Connectors 230 Volt, 50 Hz 2.3.2 DMX DMX 512 Standard input/output Please see printing on the case for the right Pin usage! [+] = Pin 3 / [-] = Pin 2 / [Ground] = Pin 3 The DMX- Address starts at the 0 at the DMX- Address [001] (from software version P 3.0).
  • Page 10: The Menu Field

    Menu Field 3.1 DMX- Channel Addressing Right after turning on the 0 you can see the current DMX- Address. Choose this as follows. Select the DMX-Level and press the menu key. This level is called on automatically after turning on the Select the figure you want to adjust by pressing the Cursor key.
  • Page 11: Read Outs Of Lamp And Unit Running Time

    3.2 Read outs of Lamp and Unit Running Time. Select the time level by pressing the Menu key twice. Select the requested time by pressing the Cursor key, 3.2.1 Lamp Time 1 The current lamp time is shown alternating with LA 1. This is the total hours used in the current lamp.
  • Page 12: The Test Level

    3.4 The Test Level The Test Level makes a function test or a self test procedure possible. 3.4.1 Self test Procedure Select the requested test level by pressing the Cursor key. Start the Self test program by pressing the Data+ key. The lamp can be started by pressing the Data+ and Data- keys for 5 seconds at the same time.
  • Page 13: Channel Selection ( Overview Table )

    Channel selection ( Overview table ) Channel Description DMX-Value Hex-Value Value % 1) Head Head position, High Byte (0 -360 0 - 255 0 - FF 0 – 100% 2) Head Head position, Low Byte (0 -1,41 0 - 255 0 - FF 0 –...
  • Page 14 Channel Description DMX-Value Hex-Value Value % 8) Color color 6 (pink) 50 - 54 32 - 36 19 – 20% bi (pink – turquoise) 55 -59 37 - 3B 21 – 22% color 7 (turquoise) 60 - 64 3E - 40 23 –...
  • Page 15 Channel Description DMX-Value Hex-Value Value % rotation cw slow . fast 124 – 191 80 - BF 50 – 74% Stop rotation ccw slow – fast 193 – 255 C1 - FF 76 – 100% 15) Gobo 2 Stop 0 – 15 0 - F 0 –...
  • Page 16: Lamp Installation

    Lamp Installation For a hassle free Lamp Installation, it is absolutely necessary to follow all descriptions in this chapter step by step. 5.1 Safety Rules • Unplug AC power connection • Allow to cool (min. 30 minutes) • Don’t touch lamp with bare fingers. •...
  • Page 17: How To Install New Lamp

    5.2 How to Install lamp Please see Illustration 1 -1 and 5-1/2. 1. Unscrew screws on the head with 8mm wrench. 2. Press the two safety levers at the same time and lift carefully the head plate. 3. Remove Sub-D socket by pressing the safety clips. Hang out the safety loop and lift the head plate cautiously.
  • Page 18: Gobo Replacement

    Gobo Replacement The PATEND-LIGHT 1200 is fitted with standard Gobos (37,5 mm, picture size 27,0 mm). To change one of these it is necessary to open the 0 and to remove the optical system. 6.1 Safety Rules • Unplug AC power connection •...
  • Page 19 Illustration 6-1 Attention: Make sure that the optical slide in fits in both grooves !!! If you use Glass-Gobos make sure that the mirror side faces the lamp side. (V1.2)
  • Page 20: Maintenance

    Maintenance The cleaning of the inner optical System, color filters, color correction filter and lenses should be done by qualified technician only! Contact your local ELATION Dealer for details. DO NOT use strong detergents, acid etc. for cleaning the case.
  • Page 21: Cleaning The Outside Optical System

    7.1.2 Cleaning the outside Optical System Illustration 7-2 1. Unscrew screws on the head with 8mm wrench. 2. Press the two safety levers at the same time and lift carefully the head plate. 3. Remove Sub-D socket by pressing the safety clips. Hang out the safety loop and lift the head plate cautiously.
  • Page 22: Ventilation System

    7.2 Ventilation System Illustration 7-3 It is necessary to clean the fan openings, air channels and fan gratings on a regular base (depending on environment). (V1.2)
  • Page 23: Technical Data /Overview

    Technical Data /Overview • Supply Data 230V/10AT • 1200 HMI W/S Lamp, bilateral based, with 750h Lamp Life • Capacitor compensation • DMX 512 Standard • Angle of spread 16° • weight 32 kg • Dimensions: 566 x 434 x 395 mm •...
