(preferably by hooking it into
8
the headlight housing).
128
Remove bulb 3.
z
Installing high-beam/low-
beam headlight bulb
Replace the defective bulb.
Bulb for low-beam head-
light
H7 / 12 V / 55 W
Bulb for high-beam
headlight
H7 / 12 V / 55 W
Install bulb 3, making sure that
lug 4 is pointing up and that
the bulb is securely seated.
Engage spring retainer 2 on
left and right.
Install plug 1.
Side-light bulbs, left and
right
The procedure for replacing the
left side-light bulb is described
below. The procedure for repla-
cing the right side-light bulb is
analogous.

Replacing parking-light

bulb
If it is not standing firmly,
the motorcycle could topple
in the course of the operations
described below.
Always make sure that the
