R 1200 RT
Technical data and colors
Engine:
Type:
• Air/oil-cooled flat twin ('Boxer') 4-stroke engine, two camshafts and four radially aligned
valves per cylinder, central balancer shaft
Bore / stroke:
• 101 mm x 73 mm
Capacity:
• 1,170 cc
Rated output:
• 81 kW (110 hp) at 7,750 rpm
Max. torque:
• 120 Nm at 6,000 rpm
Compression ratio:
• 12.0 : 1
Mixture control / engine management:
• Electronic intake pipe injection / BMS-K+ digital engine management with overrun fuel
cut-off, twin spark ignition
Emission control:
• Closed-loop 3-way catalytic converter, emission standard EU-3
Performance / fuel consumption:
Maximum speed:
• over 200 km/h
Fuel consumption over 100 km at constant 90 km/h:
• 4.1 l
Fuel consumption over 100 km at constant 120 km/h:
• 5.2 l
Fuel type:
• Unleaded super and premium, octane number 95-98 (RON) (knock sensor; rated
output at 98 RON)
Electrical system:
Alternator:
• three-phase alternator 720 W
Battery:
• 12 V / 19 Ah, maintenance-free
BMW Motorrad
Tour
R 1200 RT
Updated: October 2009
Power transmission:
Clutch:
• Single dry plate clutch, hydraulically operated
Gearbox:
• Constant mesh 6-speed gearbox with helical gear teeth
Drive:
• Shaft drive
Chassis / brakes:
Frame:
• Two-section frame consisting of front and rear sections, load-bearing engine-
gearbox unit
Front wheel location / suspension:
• BMW Motorrad Telelever; stanchion diameter 35 mm, central spring strut
Rear wheel location / suspension:
• Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut
(travel-related damping), spring pre-load hydraulically adjustable (continuously variable)
at handwheel, rebound damping adjustable
Travel front/rear:
• 120 mm / 135 mm
Wheelbase :
• 1,485 mm
Castor :
• 116 mm
Steering head angle:
• 63.8°
Wheels:
• Cast aluminium wheels
Rim front:
• 3.50 x 17"
Rim rear:
• 5.50 x 17"
Tyres front :
• 120/70 ZR 17
Tyres rear:
• 180/55 ZR 17
Brake front:
• Dual disc brake, floating brake discs, diameter 320 mm, four-piston fixed calipers
Brake rear:
• Single disc brake, diameter 265 mm, double-piston floating caliper
ABS:
• BMW Motorrad Integral ABS (part-integral)
The Ultimate
Riding Machine
