Service
Manual
Skyair R(Y)K Series
l Addition of FUY, FVY-L, FAY-FA,
FHYC140KVE Models
R71, 100KVAL, R125KTAL Models
[Applied Models]
lSkyair : Cooling Only
lSkyair : Heat Pump
Si-71A
