Page 1: Installation Manual
INSTALLATION MANUAL Split System air conditioners Installation manual English Split System air conditioners FHC35B7V1 FHYC35B7V1 FHC45B7V1 FHYC45B7V1 FHC60B7V1 FHYC60B7V1 FHYC71B7V1 FHYC100B7V1 FHYC125B7V1 FHC35BZ7V1 FHYCP35B7V1 FHC45BZ7V1 FHYCP45B7V1 FHC60BZ7V1 FHYCP60B7V1 FHYCP71B7V1 FHYC35BZ7V1 FHYCP100B7V1 FHYC45BZ7V1 FHYCP125B7V1... - Page 2 File Tecnico di Costruzione DAIKIN.TCF.004 / DAIKIN.TCF.016 e giudicato positivamente da KEMA secondo il Certificato 59277-KRQ/ECM95-4233 / 81728-KRQ/EMC98-4341. fi ˆ˜ ÚÔÛ‰ÈÔÚ›˙ÂÙ·È ÛÙÔ ∞Ú¯Â›Ô ∆¯ÓÈ΋˜ ∫ ·Ù·Û΢‹˜ DAIKIN.TCF.004 / DAIKIN.TCF.016 Î·È ÎÚ›ÓÂÙ·È ıÂÙÈο · fi ÙÔ KEMA Û‡Ìʈӷ Ì ÙÔ ¶ÈÛÙÔ ÔÈËÙÈÎfi 59277-KRQ/ECM95-4233 / 81728-KRQ/EMC98-4341.
- Page 3 ≥1500 ≥1500 ≥1500 ≥1500 ➅ 910 1 860~910 ≥ 20 ≥ 20 860 ~ 910* ≤ 35 ≤ 35 ±10mm...
- Page 4 (5) (6) SETTING...
-
Page 5: Before Installation
1 pc. ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR 1 pc. OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE SPECIFICALLY DESIGNED FOR USE WITH THE EQUIPMENT AND HAVE THEM INSTALLED BY A PROFESSIONAL. -
Page 6: Selecting Installation Site
1. Select an installation site where the following conditions For the following items, take special care during are fulfilled and that meets your customer’s approval. construction and check after installation is finished • Where optimum air distribution can be ensured. •... -
Page 7: Preparations Before Installation
• For other installation than standard installation, contact your • Check if the unit is levelled at all four corners with a water Daikin dealer for details. level or a water-filled vinyl tube as shown in figure 14. Water level... -
Page 8: Refrigerant Piping Work
REFRIGERANT PIPING WORK • If the refrigerant gas leaks during the work, ventilate the area. A toxic gas is emitted by the refrigerant gas being exposed to For refrigerant piping of outdoor unit, refer to the installation a fire. manual supplied with the outdoor unit. •... -
Page 9: Electric Wiring Work
ELECTRIC WIRING WORK NOTE • The incline of attached drain hose should be 75mm or less General instructions so that the drain socket does not have to stand additional force. • All field supplied parts and materials and electric works must •... -
Page 10: Wiring Example And How To Set The Remote Controller
WIRING EXAMPLE AND HOW TO SET THE 5 For the remote controller wiring, refer to the "Installation manual of the remote controller" supplied with the remote REMOTE CONTROLLER controller. How to connect wiring (see figure 13) Note The customer has the ability to select the remote controller •... -
Page 11: Field Setting
PRECAUTIONS Air Filter contamination 1. All transmission wiring except for the remote controller wires Setting Display interval Mode n° 1st code n° 2nd code n° is polarized and must match the terminal symbol. ±2500 hrs Light 10 (20) 2. In case of group control, perform the remote controller wiring ±1250 hrs to the master unit when connecting to the simultaneous Heavy... -
Page 12: Test Operation
8. Detach the remote controller from the slave unit after the TEST OPERATION setting, and reattach to the master unit. This is the end of the setting procedure. Refer to the section of “FOR THE FOLLOWING ITEMS, TAKE • You do not need to rewire the remote controller from the SPECIAL CARE DURING CONSTRUCTION AND CHECK master unit if the optional remote controller for slave unit is AFTER INSTALLATION IS FINISHED”... -
Page 13: Wiring Diagram
WIRING DIAGRAM :FIELD WIRING :BLACK :TERMINAL :RED :CONNECTOR :WHITE :YELLOW :WIRE CLAMP :PROTECTIVE EARTH (SCREW) 33H ....FLOAT SWITCH RECEIVER/DISPLAY UNIT (ATTACHED TO WIRELESS REMOTE CONTROLLER) A1P ....PRINTED CIRCUIT BOARD A2P,A3P ..PRINTED CIRCUIT BOARD C1R ....CAPACITOR (FAN MOTOR) BS .... - Page 14 4PW10740-1 Zandvoordestraat 300, B-8400 Oostende, Belgium...
