Colorful C.945PL User Manual page 5

Part
PCIE_16X&PCIE1
PCIE1
PCI1-PCI3
CPU_FAN
Power ATX
ATX_12V
DIMM1-DIMM4
JKB
JP1
IR
IDE1
AUXF AN1&SYS
FAN2
CLR_CMOS
CN_IN1
F_AUDIO
SATA1-SATA4
FDD1
USB1/USB2
J1
BAT1
SP1
Motherboard Parts schedule
Graphics Cards Slot
PCI Express x1 Slot
3 x 32bit PCI Slots
CPU Fan Connector
ATX Power Connector
P4 ATX Power Connector
2 x 240-pin 1.8V DDR2 Socket
Keyboard/Mouse wake up
PCI Express x1/x4 control Slot
IrDA Connector
IDE Connector
System Fan Connector, like case fan
Clear CMOS jumper
CD-in Audio Connector
Front Panel Audio
4 x Serial ATA Connector
Floppy Disk Connector
Extend USB Port
Front Panel Switch, LEDs and Speaker
Battery Container
Integrate Speaker
Use Description
PCI Express x16
PCI Express x1
PCI Slots
4 PIN
24PIN
4PIN
240PIN DIMM
3PIN
8PIN
4PIN
40PIN
3PIN
3PIN jumper
4PIN
9PIN
7PIN
34PIN FDD
9PIN
Connector 13PIN
Battery Container
Speaker
