Colorful C.945PL User Manual page 14

FAN Power Heads: AUXF AN1&SYS AN1
1 2
Pin Symbol
4
3
No
5 6
1 MIC
7
8
3 REF
9
5 FrontAudio(R)
10
7 Empty
F_Audio_AC97
9 FrontAudio(L)
Front Audio Jack
These two fan heads is very
important in you installation. It's the
power supply of the fan which to
reduce the system and the CPU
temperature.
Pin Symbol
No
2 GND
4 Power
6 RearAudio(R)
8 No Pin
10 RearAudio(L)
