This section instructs you on how to service each component inside the air conditioner. The
components and their locations are shown below.
Overload Protector
Compressor
Capacitor
Power Cord
Fan Speed Control
Models ACQ058MM
& ACQ062MM Use An
Electronic Control Assembly
Instead Of Manual Controls

COMPONENT ACCESS

COMPONENT LOCATIONS

Temperature
Sensor Tube
Temperature Control
Evaporator
Models ACQ058MM &
ACQ062MM Use A
Thermistor In Place Of A
Temperature Sensor Tube
3-1
Condenser
Fan Motor
