POWER ON
L1
COMPRESSOR ON
L1
Electronic Control Board
L1
FAN MOTOR ON
L1
Electronic Control
L1
STRIP CIRCUITS
Electronic (ACQ) Models Only
Electronic Control Board
L1
L2
Comp.
YL
Turbo
High
Low
WH
Overload
BK
BK
BU
RD
6-4
Compressor
S
BR
C
WH
R
3-Speed Motor
BR
S
T
Capacitor
G
H
GN
L
L2
L2
L2
