Special functions
Fixed channels
Free patch of one of the scan
functions
Adaptation of the colour mix
function
78 78 78 78
78
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de
FIXED CH1 :
FIXED CH2 :
This functions enables you to set two channels to a fixed
level. This channel must be connected first to an unused
function of the Scancommander. Than it can be fixed in
the FIXED CH1 resp. FIXED CH2 menu to a specific level.
Later this channel will not be affected by any function of
!
the Scancommander.
(For example: The (Lightwave research) Studiocolor needs
channel 16 to be set at 00).
FREEPATCH : -----
The last function of the filed channel list can be sepa-
rated optionally from the other DMX channels of the scan.
Later this function can be patched separately. Therefore it
must be selected by the third encoder.
(Example: In the VL5 of Vari*Lite the dimmer is separated
from the other control channels and is controlled by an
external dimmer. By the FREEPATCH function this dim-
mer address can be entered separately)
If a lamp was defined in the FREEPATCH menu it will
appear in the LAMPTYPE SETUP menu as follows:
SCAN
DIMMER
C-M-Y MODE :
Up to now the scan manufacturers do not agree to an
uniform colour mix. Some work with C-M-Y, others with
the R-G-B colour mix. To reach a better control of the
colour mix function the C-M-Y function can be inverted.
---- , 0%
---- , 0%
- button
here the lamp can be selected and patched
separately
NORMAL (optionally INVERS)
