Explanation of the different
parameters
Mirror or headlamp
Channel order
76 76 76 76
76
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn . Fax: + 49 9 31 4 97 94 29 . www.malighting.de
NAME :
SHORT NAME :
The name of the lamptype (19 characters) and the
shortname (6 characters) can be entered by the keyboard
SCANTYPE :
Selection of MIRROR or HEAD (e.g. Vary* lites). This
function is only valid for the stage movements.
CHANNELS :
EDIT
leads to the menu for the channel order:
CH. 1 : GOBO2
CH. 2 : TILT
CH. 3 : GOBO1
CH. 4 : COLOR1
CH. 5 : DIMMER
CH. 6 : PRISMA
CH. 7 : CYAN
CH. 8 : YELLOW
CH. 9 : COLOR2
CH.10 : GO1-ROT
CH.11 : MAGENTA CH.23 : ----
CH.12 : FOCUS
USER 1
ENCODER 2 and 3:
Selection of the DMX channel (inverse) and the corres-
ponding function. These channels must be selected and
set up one by one.
24 channels can be programmed to the functions of the
Scancommander. These functions can be selected by
encoder 3 in the following order:
Gobo 1
Gobo 2
Color 1
Color 2
Dimmer
Cyan
Magenta
Yellow
Prism
Iris
Focus
Frost
`MY_SCAN1 1 XYZ 199 ´
`MS1 ´
MIRROR
17
CH.13 : PAN
CH.14 : IRIS
CH.15 : SPEED1
CH.16 : FROST
CH.17 : SHUTTER
CH.18 : ----
CH.18 : ----
CH.20 : ----
CH.21 : ----
CH.22 : ----
CH.24 : ----
CHAN. 1
CLEAR
RETURN
GOBO 2
Zoom
Shutter
Speed 1
Speed 2
Special
Gobo1-Rotation
Gobo2-Rotation
Prism Rotation
Pan
Pan fine
Tilt
Tilt fine
