Short name: CHAN 1
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Dimmer 2: Color 1
4: Shutter 5: Pan
7: Rotation
———————————————————————————
Scan type: CHANDRA II
Short name: CHAN 2
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Color 1
4: Shutter 5: Pan
7: Dimmer 8: G.Swing=Rot. 1 9: Focus
10: Rotation 3 11: Gobo 2
———————————————————————————
Scan type: SWING II 16 BITS
Short name: SWING2
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Color 1
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: G.Swing=Rot. 1 11: Focus
13: Gobo 2 14: G.Rot.=Rotation 2
Presets available.
———————————————————————————
Scan type: CHANDRA II 16 BITS
Short name: CHAN 2
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Iris 2: Color 1
4: Shutter 5: Pan coarse
7: Tilt coarse 8: Tilt fine
10: G.Swing=Rot. 1 11: Focus
13: Gobo 2 14: Rotation 2
———————————————————————————
Manufacturer LYTE QUEST
Scan type: MOTORHEAD
Short name: MOTORH
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Gobo 1 5: Dimmer
———————————————————————————
Manufacturer MAD LIGHTING
Scan type: QSCAN
Short name: CSCAN
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Color 1 5: Dimmer
———————————————————————————
Scan type: SCAN 611
Short name: SCAN61
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Color 1 5: Dimmer
———————————————————————————
Manufacturer MARTIN
Scan type: ROBOSCAN 804/805/1004/16
Short name: R 805
Movement: Mirror - No Brightness Master
DMX channel order
1: Shutter 2: Color
4: Pan 5: Tilt
Presets available.
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander
3: Gobo 1
6: Tilt
3: Gobo 1
6: Tilt
12: G.Rot=Rotation 2
3: Gobo 1
6: Pan fine
9: Dimmer
12: Color 2
Protocol: DMX 512
3: Gobo 1
6: Pan fine
9: Dimmer
12: Rotation 3
3: Color 1
3: Gobo 1
3: Gobo 1
6: Rotation
3: Gobo 1
———————————————————————————
Scan type: PRO 218 M2
Short name: PRO218
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Gobo 1 5: Pan
7: Speed
Presets available
———————————————————————————
Scan type: PRO 218 Mode3 High Res.
Short name: PRO218
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Gobo 1 5: Pan coarse
7: Tilt coarse 8: Tilt fine
Presets available
———————————————————————————
Scan type: PRO 518
Short name: PRO518
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Gobo 1 5: Prism
7: Tilt 8: Speed 1
Presets available.
———————————————————————————
Scan type: PRO 518 H.Res Mode 3
Short name: PRO518
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Gobo 1 5: Prism
7: Pan fine 8: Tilt
Presets available.
———————————————————————————
Scan type: PRO 812
Short name: PRO812
Movement: Mirror - Brightness Master on Shutter
DMX channel order
1: Shutter 2: Color 1
4: Pan 5: Tilt
7: Speed 2
Presets available.
———————————————————————————
Scan type: PRO 918 MODE 4
Short name: PRO918
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Color 2 5: Gobo 1
7: Gobo 2 8: Focus
10: Prisma 11: Pan
13: Tilt 14: Tilt fine
Speed 2
———————————————————————————
Scan type: R 1020
Short name: R 1020
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Shutter 2: Dimmer
4: Color 2 5: Gobo 1
7: Focus 8: Iris
10: Pan 11: Tilt
Presets available.
———————————————————————————
Scan type: R 1220
Short name: R 1220
Movement: Mirror - Brightness Master on Dimmer
3: Color 1
6: Tilt
3: Color 1
6: Pan fine
3: Color 1
6: Pan
9: Speed 2
3: Color 1
6: Pan
9: Tilt fine
3: Gobo 1
6: Speed 1
3: Color 1
6: Rotation 1
9: Iris
12: Pan fine
15: Speed 1 16:
3: Color 1
6: Gobo 2
9: Prism
12: Speed 1
