MA lighting SCANCOMMANDER User Manual page 41

Scancommander Scancommander Scancommander Scancommander Scancommander
Programming of
sequence steps
Individual and freely
adjustable step numbers
Different GO MODES
STEP TIME for timed step
following
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander
INSERT
1.0
2.0
2.1
2.2
3.0
......
6
Compared to programming a chaser step the following functions are
available:
ENCODER 2
STEP MODE buttons at the Sequence Playback
MAN FADE
GO BUTTON
EXT SOUND
SET RATE
STEP TIME and
ENCODER 3
DELETE
ALL
PROGRAM
SEQUENCE
1
SEQUENCE:
STEPS: 5
(94770)
FREE:
NO NAME
3.5
STEP :
Each step has its individual number from 0.0 up to
99.9. Like a name this number will stay with the step
during all copy and move operations.
Encoder wheel: first digits
Encoder ring: digits after the decimal point
Sets the GO MODE for this step, which marks, how
the step will be recalled when running the sequence.
The selected mode is shown by the LED inside its
respective button and is displayed on top of encoder
1.
Manual x-fade via the X-FADER in the sequence area.
The step has to be recalled by the GO button.
The step will wait for a sound impulse.
The step will be recalled automatically, as soon as
the STEP TIME of the last step runs out.
Sets the time between this step and the start of the
next one, if the next one is on GO MODE "SET
RATE".
SINGLE
STEP TIME
1.00 sec
LINK FADE
STEP FADE
0.00 sec
STEP TRIG
0 %
41 41 41 41
