! STORE !
button in the DISPLAY
Initializes the new movement. Changing to
the next scan without STORE will clear the
register of the corner positions.
Heading the first corner on the left
backside of stage with the beam (To be
sure to get the same corner points for
all the scans, the corners should be
marked on stage with white tape
crosses.)
As soon as the beam meets the corner
point,
- button
SET
stores the position in a temporary data
register. The mark "
this corner was already adjusted.
Heading the second corner
- button
SET
Heading the third corner
- button
SET
Heading the fourth corner
- button
SET
" shows, that
