MA lighting SCANCOMMANDER User Manual page 101

Scancommander Scancommander Scancommander Scancommander Scancommander
4: Gobo1 5: Rotation 1
7: Shutter 8: Prisma
Presets available
———————————————————————————
Scan type: ADVERT SCAN HR
Short name: ADVERT
Movement: Mirror - No Brightness Master
DMX channel order
1: Pan 2: Tilt
4: Gobo 1 5: Rotation 1
7: Focus 8: (not used)
10: Pan fine 11: Tilt fine
———————————————————————————
Scan type: SC-250
Short name: SC-250
Movement: Mirror - Brightness Master on Shutter
DMX channel order
1: Pan 2: Tilt
4: Gobo 1 5: Rotation 1
———————————————————————————
Scan type: SC-530/570 HR
Short name: SC-530
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Spped 1
7: Color 1 8: Gobo 1
10: Pr.-Rotation
———————————————————————————
Scan type: SC-740 HR
Short name: SC-740
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Spped 1
7: Color 1 8: Gobo 2
10: (no used) 11: Gobo 1
13: Iris
———————————————————————————
Scan type: SC-780 HR
Short name: SC-780
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Spped 1
7: Color 1 8: Gobo 2
10: Pr.-Rotation 11: Gobo 1
13: Iris 14: Focus
16: Dimmer
———————————————————————————
Scan type: SC-940/980 HR
Short name: SC-940
Movement: Mirror - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Spped 1
7: Color 1 8: Color 2
10: Gobo 2 11: Gobo 1
13: Iris 14: Focus
16: Dimmer
eMail: info@malighting.de . Tel.: + 49 9 31 49 79 40 . User's Manual Scancommander
6: Iris
3: (not used)
6: Special
9: Speed 1
3: Color 1
6: Shutter
3: Pan fine
6: Special
9: Dimmer
3: Pan fine
6: Special
9: Dimmer
12: Rotation 1
3: Pan fine
6: Special
9: Prisma
12: Rotation 1
15: Shutter
3: Pan fine
6: Special
9: Prisma
12: Rotation 1
15: Shutter
———————————————————————————
Scan type: MH 640 WASHLIGHT
Short name: MH 640
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Speed 1
7: Color 1 8: Cyan
10: Yellow 11: Speed 2
13: Prisma 14: (no used)
16: Dimmer
———————————————————————————
Scan type: MH 660 SPOT HR
Short name: MH 660
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Speed 1
7: Color 1 8: (no used)
10: Pr.-Rotation 11: Gobo 1
13: (no used) 14: Focus
16: Dimmer
———————————————————————————
Scan type: MH 840 WASHLIGHT
Short name: MH 840
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Speed 1
7: Color 1 8: Cyan
10: Yellow 11: Speed 2
13: Prisma 14: Zoom
16: Dimmer
———————————————————————————
Scan type: MH 860 SPOT
Short name: MH 860
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Pan 2: Tilt
4: Tilt fine 5: Speed 1
7: Color 1 8: Color 2
10: Gobo 1 11: Gobo 2
13: Iris 14: Zoom
16: Dimmer
———————————————————————————
Manufacturer GENIUS
Scan type: OMEGA 2
Short name: OMEGA2
Movement: Head - Brightness Master on Dimmer
DMX channel order
1: Special 2: Color 1
4: Shutter 5: Pan
7: Dimmer 8: Prisma
10: Rotation 2
———————————————————————————
3: Pan fine
6: Special
9: Magenta
12: Color 2
15: Shutter
3: Pan fine
6: Special
9: Prisma
12: Rotation 1
15: Shutter
3: Pan fine
6: Special
9: Magenta
12: Color 2
15: Shutter
3: Pan fine
6: Special
9: Prisma
12: Rotation 1
15: Shutter
3: Gobo 1
6: Tilt
9: Gobo 2
