3-12 C 3: C
HAPTER ONFIGURATION

Conventions

U T A
SING RANSCEND
Download/Upload File . (IP only) Allows (1) AccessBuilder
configuration parameters to be uploaded to a specified TFTP server, (2)
configuration parameters to be downloaded from a specified TFTP server to
a specified AccessBuilder, (3) AccessBuilder server image to be downloaded
form a TFTP server to a specified AccessBuilder.
System Configuration Parameters. Opens a dialog box to configure
system-related parameters, such as server name, date, time, greeting, etc.
Protocols. Allows specified protocol-related parameters to be enabled or
disabled.
Modem Scripts. Allows modem scripts to be added, created, edited or
deleted.
Async Ports. Allows the specified asynchronous port-related parameters
to be changed.
Remote Users. Allows remote user-related parameters such as phone
number, password, etc., to be added, deleted or changed.
SNMP. Allows defining or redefining of the set of SNMP managers-related
parameters or copying them to another AccessBuilder server.

Port Color Conventions

The asynchronous ports and ISDN channel indicators are color-coded to
show status, as shown in the table below:
Table 3-3 Port Color Conventions
Color Meaning
White Not in use
Green In session (dial in)
Cyan (Greenish blue) In session (dial out)
Blue Disabled
Yellow Router (LAN-to-LAN)
Double-click any asynchronous/ISDN port in the graphical image to
configure asynchronous/ISDN port parameters for that port. Use the
B M (TABM)
CCESS UILDER ANAGER
