3-10 C 3: C
HAPTER ONFIGURATION
Main Window (All
Servers List View)
Menu Bar
Toolbar
Info read from
server highlighted
in Server List
Server List lists
all servers that
respond to auto
discovery
Status Bar
Status Bar
describes
current
function in
process
AccessBuilder
Server External
View
U T A
SING RANSCEND
The main window appears when you first start the application. The main
window lists all servers known to the application by IP/IPX address and
user-defined name.
Figure 3-9 AccessBuilder Manager Main Window (IP version shown)
Highlighting any server in the All Server List displays information about
that server in the top half of the main window. The IP address and name
data fields in the statistics dialog box are editable, allowing you to change
the server's name and add a new IP address.
To display the external view of any listed server, double-click that server's
address/name in the server list of the main window.
The external view displays a graphical image of a single AccessBuilder
remote access server.
B M (TABM)
CCESS UILDER ANAGER
Displays the Single
Server External view
of the highlighted
AccessBuilder
Shows specific
information about
highlighted
server
Choose to add
a server
Choose to delete
highlighted
server
Use to change
AccessBuilder info
Accesses the online
help
