Name of server
Menu Bar
Tool Bar
ISDN B - channel
status indicators:
left = B2
right = B1
Copy Server
Configuration
Double-click this area to view the
Asynchronous Port dialog box for the
desired port
Figure 3-10 External View (Ethernet LAN Adapter shown)
Tool Bar Icons
The icons in the tool bar shown above are convenient shortcuts to selecting
commands from the Menu bar. They are defined in Figure 3-11:
Download/
System
Verify
Upload
Config.
File
Figure 3-11 Tool Bar Icon Definitions
Copy Server Configuration. Copies the current server configuration to
a specified AccessBuilder.
Verify Configuration. Displays current status of critical AccessBuilder
configuration information.
About the TABM Application
IP address of server
Double-click this
area to view the
LAN statistics
dialog box
Protocols
Modem
Async
Scripts
Ports
Double-click the logo for info on
the current software version
SNMP
Remote
Users
3-11
