3Com ACCESSBUILDER 4000 Installation Manual page 26

2-8 C 2: G
HAPTER ETTING
Thin Ethernet
Connection
S
TARTED
When using an external 10Base5 (thick Ethernet) transceiver, the
AccessBuilder's LAN controller test will fail if the BNC interface is NOT
terminated. If this happens, be sure that a 50-ohm BNC termination resistor
is installed on each end of your cable run and reboot the system.
2 Install and connect your I/O card (or cards) to your modems, CSU/DSU, ISDN
line, etc. Refer to Appendix C for details.
3 (Console connection -- optional step) Connect a terminal or a PC running
terminal emulation (DTE) with a straight-through cable to the
AccessBuilder's console port (DCE). Default settings are 9600 Baudrate, 8
bits, 1 stop bit and no parity.
Figure 2-3 AccessBuilder Ethernet Thin LAN Connection
I
A U
E T
R N
H E
E T
C
B N
E
T P
U I /
C / A
B N
E
O L
N S
C O
2
O T
S L
2 4
0 -
1 1
0
- 6
5 0
1
O T
S L
P
U T
C
V A
0
1 A
H z
