3.

Scenes

3.1

Record a Scene

1. Press and hold down the the Record button (15) for 3 seconds to enter Record Mode.
2. The red LED next to the button lights up.
3. Select the fixture you want to program by pressing the desired Fixture button (1).
4. Set the 8 faders (5-12) to the desired values.
5. Select the proper Page by pressing the Page button (14). You can choose Page 1 or Page 2.
The orange LED above the button lights up Select the desired chase by pressing Chase button 1-8 (3).
6. Press the Record button (15). The red LED next to the button lights up.
7. Now select the scene you want to program the value into by pressing the desired Scene button (2).
8. All LEDs will flash 3 times, indicating your operation has been successful.
9. Press and hold the Record button (15) for 3 seconds to exit Program Mode
The existing scenes will be overwritten
3.2

Play a Scene

1. Deselect all fixtures. All LEDs next to the 8 fixture buttons (1) must be OFF.
2. Select the proper Page by pressing the Page button (14). You can choose Page 1 or Page 2.
The orange LED above the button lights up.
3. To select the desired scene press the Scene button (2).
4. Scenes can be stored on 2 pages. Each page can contain a maximum of 8 scenes.
Multiple scenes can be mixed together
Scenes will react to the Fade fader (24)
Be sure to use the Page button (14).
As an overview you are immediately able to view which scenes are still active on which page.
The LEDs, from the scene or chase that is still active, are on.
3.3

Delete a Scene

1. Deselect all fixtures, scenes and chases.
2. Press and hold down the the Record button (15) for 3 seconds to enter Record Mode.
3. The red LED next to the button lights up.
4. Select the proper Page by pressing the Page button (14). The orange LED next to the button lights up
5. Press and hold the Tap Sync button (16). Now press the corresponding Scene button (2), that you
want to delete.
6. All LEDs will flash 3 times, indicating your operation has been successful.
7. Exit Record Mode by pressing the Record button (15).
