LED Diagnostics:
AL600ULXB - Power Supply Board
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
PD4/PD4CB/PD8/PD8CB - Power Distribution Module
Green Power Distribution Module Status
ON Normal operating condition.
Terminal Identification:
AL600ULXB - Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 115VAC to these terminals: L to Hot, N to Neutral, G to ground.
- DC + 12VDC @ 10 amp continuous non-power limited output.
AC FAIL Used to notify loss of AC power, e.g. connect to annuciator/alarm panel. Relay normally energized
N.C., C, N.O. when AC power is present. Contact rating 1 amp @ 30VDC. AC Fail condition will report
approximately one (1) to one minute after loss of AC. To delay report for 6 hours cut jumper
J1 on the Power Supply Board (AC trouble output delay option). If this mode is selected the Power
Supply Board must be reset by removing all power to it for 30 seconds.
BAT FAIL Used to indicate low battery condition, e.g. connect to alarm panel. Relay normally energized
N.O., C, N.C. when DC power is present. Contact rating 1 amp @ 30VDC. Low battery conditions will report
approximately 10.5VDC Battery presence detection will report approimately 1 minute after battery
remains undetected (missing or removed).
- BAT + Stand-by battery connections. Maximum charge rate .7 amp.
PD4/PD4CB/PD8/PD8CB - Power Distribution Module
Terminal Legend
PD4/PD4CB
1P to 4P
1N to 4N
Power Supply Status
Normal operating condition
Loss of AC, Stand-by battery supplying power
No DC output
Loss of AC. Discharged or no stand-by battery. No DC output.
PD8/PD8CB
1P to 8P
1N to 8N
Function/
Description
Positive DC power outputs.
Negative DC power outputs.
