Chapter 1
1.1 Specifications
System
Intel® Atom Processor D2550 (1M Cache, 1.8 GHz)
CPU
Intel® Atom Processor N2600 (1M Cache, 1.6 GHz) option
System Chipset
Intel NM10 Express
System Memory Onboard 2GB DDR3 800 MHz
IO Port
USB
1 x M12 8 pin for USB 1/2
1 x M12 8 pin for USB 3/4
Serial/Parallel
1 x M12 8pin for COM 1/RS-232/422/485 (Default RS-232)
1 x M12 8pin for COM 2/RS-232
Audio
None
Graph
None
LAN
1 x M12 8pin for LAN 1
Digital I/O
None
KB/MS
None
Membrane
None
control
Power
1 x M12 3 pin DC power connector
Storage Space
1 x 2.5" HDD space
HDD
Movable device
1 x Internal SD slot
Expansion
On board
1 x Mini PCIe half size
expansion bus
Expansion slot
None
Display
Display Type
Max. Resolution
Max. Color
Luminance
(cd/m²)
View
angle(H°/V°)
APC-3x97B User Manual
APC-3597B
15" Color TFT LCD
1024x768
262K
400
160/145
APC-3797B
17" Color TFT LCD
1280x1024
16.7M
350
170/170
System
APC-3997B
19" Color TFT LCD
1280x1024
16.7M
350
170/160
6
Advertisement
Related Manuals for Aplex APC-3597B
Summary of Contents for Aplex APC-3597B
-
Page 1: Specifications
Chapter 1 System 1.1 Specifications APC-3597B APC-3797B APC-3997B System Intel® Atom Processor D2550 (1M Cache, 1.8 GHz) Intel® Atom Processor N2600 (1M Cache, 1.6 GHz) option System Chipset Intel NM10 Express System Memory Onboard 2GB DDR3 800 MHz IO Port... - Page 2 Contrast Ratio 800:1 1000:1 1000:1 Backlight 50000 50000 50000 lifetime(hrs) Touch screen Type Resistive Type Interface RS-232 Light Transmission Power Power Input 11~32V DC Mechanical Stainless steel Construction Total IP65 IP Rating Mounting VESA 75 x 75 Dimension 399 x 324 x 52.5 432 x 358 x 57 470 x 388.6 x 60 (mm)
- Page 3 1.2 Dimensions Figure 1.2: Dimensions of APC-3597B Figure 1.3: Dimensions of APC-3797B APC-3x97B User Manual...
- Page 4 Figure 1.4: Dimensions of APC-3997B APC-3x97B User Manual...
- Page 5 1.3 Brief Description of APC-3x97B APC-3X97B series comes with IP65 certificated and is powered by Intel Atom D2550 to provide low power consumption. The stainless steel chassis design makes it exceptionally suitable for strict hygiene regulations for food/chemical industry, medical, restaurant/kitchen applications, storage management and outdoor /information segment and so on.
-
Page 6: Main Board
Chapter 2 Hardware 2.1 Mainboard Specifications 170mm x 113mm Board Size Intel® Atom Processor D2550 (1M Cache, 1.8 GHz) CPU Support Intel® Atom Processor N2600 (1M Cache, 1.6 GHz) option Intel NM10 Express Chipset Onboard 2GB DDRIII SDRAM Memory Support Integrated Intel GMA 3600 (N2600) Graphics 1 x CRT Port... - Page 7 8-bit digital I/O Pin header via CN2 Digital I/O 4-bit digital Input 4-bit digital Output 4-bit digital I/O Pin header via CN3 2-bit digital Input 2-bit digital Output Support CR2477 Li battery by 2-pin header Battery Realtek ALC662 HD audio codec Audio Line-in, Line-out, MIC via 2x6-pin header Audio Line out in phone jack...
