Control Panel
3

Codepad Introduction

3.1

Codepad

IUI – SOL -TEXT
3.2

Quick Codepad Operation Instructions

3.3

Codepad Indicators

Codepad indicator
icons
ZONE 1 – 8 for ICP-
SOL2-P
ZONE 1 – 16 for ICP-
SOL3-P
AWAY
Bosch Security Systems, Inc.
Status
On
Off
Flashing Fast (0.25 sec
on/0.25 sec off)
Flashing Slow (1 sec on/1
sec off)
On
Off
Flashing twice a sec with
STAY indicator
User's Guide
Codepad Introduction | en
IUI – SOL – ICON
Definition
Zone is unsealed.
Zone is sealed.
Zone is in alarm condition.
Zone is manually isolated or selected to
be isolated.
System is armed in AWAY Mode.
System is not armed in AWAY Mode.
Setting STAY Mode 2 zones.
2014.05 | 01 | F01U298028
7
