7.3. Where to use
The grinder should be installed on a flat, stable surface. The minimum
dimensions of the work space should be as follows:
Height
Width
Depth
7.4. Grinder installation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• The electrical outlet coincides with the grinder plug.
• The electric power at the location of installation should meet the minimum
required to properly run the grinder.
• The installation site should have the proper electrical overload protections.
• The grinder should be properly grounded as specified by local code.
The three-phase models are sold without the plug. In these models, you will be given
an uncovered power cable.
K04673 | v. 30/04/2014 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
Model
R8, R80, R100
28.35
720
9.45
240
13.78
350
R120, R140
35.43
900
10.43
265
16.34
415
in
mm
in
mm
in
mm
