Performance Route Processor
Installation and Configuration
Product Number: PRP-2=, PRP-3=
Document Order Number: OL-17436-01
This hardware installation and configuration note describes the performance route processor (PRP)
PRP-2 and PRP-3 route processors for use in Cisco XR 12000 Series Routers and Cisco 12000 Series
Routers.
Document Contents
This publication includes the following sections:
Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Configuring Interfaces on the PRP, page 41
Configuring Interfaces on the PRP-3, page 48
Additional Configuration and Maintenance Tasks, page 59
Regulatory, Compliance, and Safety Information, page 84
