Introduction
Congratulations on your purchase of the Hitec Eclipse Pro Car computer radio.
The Eclipse Pro Car is loaded with many great features to maximize your R/C experience.
Please read this manual carefully to familiarize yourself with the operation of your new
Eclipse Pro Car. After reading this manual, store it in a safe place for future reference.
1. System Features
A) Radio Features
- Ergonomically designed 3-channel FM computer radio.
- High definition/multi-pixel LCD display.
- Removable module for easy channel changing. (Spectra capable)
- Dual rate steering. (Adjustable while driving)
- Brake ATL switch. (Adjustable travel length)
- Digital trims.
- Trim center audible verification.
- Third channel "Shifting" switch.
- Third channel "Linear" digital trim.
- Transmitter charging jack for rechargeable batteries.
- RF (Radio Frequency) Indicator light.
- Two-speed menu scrolling.
- Transmitter low battery alarm.
- Total transmitter "On" time timer.
B) Programmable Features
- Model naming. (6 Characters)
- Model select. (20 models)
- Sub-trims.
- Ch #3 switch set. (Shift, Linear)
- EPA. (End Point Adjustment)
- Steering and throttle exponential travel.
- ABS. (Anti-Lock Braking)
- Steering to AUX/Throttle to AUX mixing.
- Timer. (Up/Down)
- Servo reversing.
- Model copy.
- Model reset. (Factory default)
