Altronix AL1002ULADA Installation Manual page 12
Nac power extender
Hide thumbs
Also See for AL1002ULADA:
- Installation manual (21 pages) ,
- Application manual (8 pages) ,
- Installation manual (17 pages)
Table of Contents
Advertisement
4.5"
(114.3mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
2.0"
(50.8mm)
2.0"
(50.8mm)
5.0"
(127.0mm)
1.25"
(31.75mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIAL1002ULADA
- 12 -
Enclosure Dimensions (H x W x D approx.):
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm)
