8.4. HORIZONTAL LINE ARRAY CONFIGURATION
The Horizontal Line Array Configuration is
another unique application of the KJ50vb.
Up to four speakers can be driven and controlled
by a single KA7-7 amplifier.
The cabinets should be positioned together and
switched to Horizontal
'Spo
t' position.
p. 12
CH. 1 near field
CH. 2 mid- near field
CH. 3 mid-far field
CH. 4 far field
Amp. Speakon 1
Ch.s 1 & 2
Amp. Speakon 2
Ch.s 3 & 4
!
