Cellular Information

The cellular/wireless performance depends on the implementation and antenna design. The integration of the

antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early

so the performance is not compromised. If changes are made to the device's certified antenna system, then

recertification will be required by specific network carriers.

There cannot be any alteration to the authorized antenna system. The antenna system must maintain the same

specifications. The antenna must be the same type, with similar in-band and out-of-band radiation patterns.

This device has been designed to operate with the antennas listed below and having a maximum gain for 850 MHz

of <= 6.4 dBi , for 1700 MHz of <= 6.5 dBi, and for 1900 MHz of <= 3 dBi. Antennas not included in this list or that

have a gain greater than specified are strictly prohibited for use with this device. The required antenna impedance

is 50 ohms.

These devices were approved with the following antenna:

Manufacturer:

Manufacturer's Model Number:

Multi-Tech ordering information:

Model

ANQB-1HRA

ANQB-10HRA

ANQB-50HRA
