Cellular Information

The cellular/wireless performance is dependent on the implementation and antenna design. The integration of the

antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early

so the performance is not compromised. If changes are made to the certified antenna system of the

SocketModem, then recertification will be required by specific network carriers such as Sprint.

There cannot be any alteration to the authorized antenna system. The antenna system must maintain the same

specifications. The antenna must be the same type, with similar in-band and out-of-band radiation patterns.

This device has been designed to operate with the antennas listed below and having a maximum gain of 3.93dBi.

Antennas not included in this list or having a gain greater than 3.93dBi are strictly prohibited for use with this

device. The required antenna impedance is 50 ohms.

GSM devices were approved with the following antenna:

Manufacturer:

Model Number:

Multi-Tech ordering information:

Model

ANHB-1HRA

ANHB-10HRA

ANHB-50HRA
