Cellular Information

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. If changes are made to the device's certified antenna system, then
recertification will be required by specific network carriers.

Cellular Antenna Information

Authorized Antenna/Antenna Specifications for Cellular Bands

The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer:
Description:
Model Number:
Multi-Tech Part Number:
Multi-Tech ordering information:
Model
ANHB-1HRA
ANHB-10HRA
ANHB-50HRA

3G Antenna Requirements/Specifications

Category
Frequency Range
Impedance
VSWR
Typical Radiated Gain
Radiation
Polarization
®
MultiConnect rCell 100 Series Router User Guide
Laird Technologies.
HEPTA-SM
MAF94300
45009735L
Quantity
1
10
50
Description
824 – 960 MHz / 1710 – 1990 MHz / 1920 – 2170 MHz
50 Ohms
VSWR should not exceed 2.0:1 at any point across the bands of operation
850 MHz
950 MHz
1800 MHz
1900 MHz
2100 MHz
Omni-directional
Linear Vertical
3.17 dBi
3.51 dBi
3.55 dBi
3.0 dBi
3.93 dBi
CELLULAR INFORMATION
17
