CELLULAR INFORMATION
Chapter 3 – Cellular Information

Antenna System Cellular Devices

The antenna system is defined as the UFL connection point from the device through the cable and antenna. Device
performance depends on implementation and antenna system design. Integrating the antenna system is a critical
part of the design process; therefore, it is essential to consider it early so the performance is not compromised.

Requirements for Cellular Antennas with regard to FCC/IC Compliance

The antenna must be the same type, with similar performance and in- and out-of-band radiation patterns as the
listed antenna. The antenna used must stay below the FCC/IC maximum gain.
For our bundles, MultiTech may change antennas over time. The listed antenna(s) is used as a reference or was
shipping when this document was last updated.
This device has been designed to operate with the antennas listed below and having a maximum gain for 850 MHz
of <= 6.4 dBi , for 1700 MHz of <= 6.5 dBi, and for 1900 MHz of <= 3 dBi. Antennas not included in this list or that
have a gain greater than specified are strictly prohibited for use with this device. The required antenna impedance
is 50 ohms.

Antenna Information

This device was approved with the following antenna:
Manufacturer:
Description:
Model Number:
Multi-Tech Part Number:
Multi-Tech ordering information:
Model
ANPB2-1HRA
ANPB2-10HRA
ANPB2-50HRA

Antenna Requirements/Specifications

Frequency range
Impedance
VSWR
Radiation
Polarization
18
San Jose
Penta band antenna
EEN-301
45009780L
Quantity
1
10
50
824-960/1710-2170 MHz
50 ohm
<2.5:1
Omni directional
Linear horizontal
®
