PRODUCT OVERVIEW

Power Draw MTR-EV3

7 volts
US Cellular 800 MHz
US PCS 1900 MHz
9 volts
US Cellular 800 MHz
US PCS 1900 MHz
32 volts
US Cellular 800 MHz
US PCS 1900 MHz
Peak Tx: The peak current during a CDMA connection transmitting data at max power.
Maximum Power: The continuous current during maximum data rate with the radio transmitter at maximum
power
Inrush Charge: The total inrush charge at power on.
10
Cellular call box Average measured
connection no data current (amps) at
(amps) maximum power
0.255 0.818
0.255 0.848
0.2 0.630
0.2 0.646
0.069 0.188
0.069 0.194
Peak TX amplitude
current (amps)
0.900
0.924
0.7
0.716
0.232
0.24
®
MultiConnect rCell 100 Series Router User Guide
Total inrush charge
measured in
MilliCoulombs (mC)
1.71
1.71
2.65
2.65
4.27
4.27
