- Page 1 Smart-heat™ eleCtriC heater BY BrOmiC InstallatIon, InstructIon and servIce manual aVaILaBLE IN 1500W VERSION ImPortant READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL.KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE. Version 1 AUS...
- Page 2 IMPORTANT this manual contains important information about the installation, operation, and maintenance of platinum Smart-heat™ electric heaters. please pay close attention to the important safety information shown throughout this instruction manual. any safety information will be accompanied by the following safety alert symbols:...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS PRODUCT FEATURES HEATER INSTALLATION INSTRUCTIONS CEILING & WALL MOUNTING CEILING RECESS UMBRELLA MOUNTING TUBE SUSPENSION CHAIN SUSPENSION ELECTRICAL INSTALLATION SERVICING REPLACEMENT PART LIST TROUBLESHOOTING WARRANTY www.bromicheating.com... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS WarnInG • Do not spray aerosols or flammable materials in the vincinty of this appliance while it is in operation • This appliance is for COMMERCIAL USE ONLY • Installation and repair must be carried out by a qualified &... -
Page 5: Product Overview
PRODUCT OVERVIEW The Platinum Smart-Heat™ Electric is designed The heaters are built with corrosion resistant materials, have to provide efficient spot heating for many commercial and electrical approval in Australia and are rated to IPX5 water industrial applications. -
Page 6: Heater Installation Instructions
HEATING INSTALLATION INSTRUCTIONS ceIlInG & Wall mountInG Brackets 1. Heater must be installed with the minimum installation Minimum distance from edge of the heater to any clearances shown in diagram. adjacent walls must be at least 250mm. Heater must be Minimum distance between heaters measured from away from the fourth wall. - Page 7 HEATING INSTALLATION INSTRUCTIONS CONTINUED... 2. Mark mounting hole centres on ceiling or wall. Brackets have 2 different mounting holes options. Mounting Hole Centres & Heater Position 3. Attach mounting brackets to ceiling or wall using appropriate fasteners (Not supplied). 4. Assemble rear brackets to heater with M5 screws. 5.
-
Page 8: Ceiling Recess
HEATING INSTALLATION INSTRUCTIONS CONTINUED... ceIlInG recess (sold seParately) WARNING Minimum vertical ceiling space clearance measured from WARNING ceiling surface must be 300mm. Instructions below are suitable for ceiling surfaces 10- Minimum horizontal ceiling space clearance measured 30mm thick. For ceiling surfaces from each edge of ceiling cut out must be 500mm. -
Page 9: Umbrella Mounting
HEATING INSTALLATION INSTRUCTIONS CONTINUED... umBrella mountInG (sold seParately) Heater position relative to mounting holes 1. Heater must only be mounted on metal umbrella arms. Heater must be installed with heater surface at least 2400mm above the floor level. Drill mounting holes in umbrella arm. 2 x Ø6.0mm holes through both sides of arm. -
Page 10: Tube Suspension
HEATING INSTALLATION INSTRUCTIONS CONTINUED... tuBe susPensIon (sold seParately) 1. Heater must be installed with heater surface at least 2400mm above the floor level. Supplied suspension tubes position heater surface 1000mm below the ceiling surface. If required, cut down length of suspension tubes to ensure correct installation height. -
Page 11: Chain Suspension
HEATING INSTALLATION INSTRUCTIONS CONTINUED... chaIn susPensIon (sold seParately) 1. Heater must be installed with heater surface at least 2400mm above the floor level. If required, cut down length of chain to ensure correct installation height. Minimum distance between heaters measured from edge of heaters must be at least 500mm. -
Page 12: Electrical Installation
ELECTRICAL INSTALLATION WARNING electrIcal InstallatIon This heater MUST be permanently installed by 1. Check product label for correct voltage and watt- an authorised/licenced person. Do not perform age - Make sure power source conforms to the heaters maintenance, or carry out installation or assembly requirements. -
Page 13: Replacement Part List
REPLACEMENT PART LIST Description Bromic Part No. Platinum Electric 1500W 2620230 Ceiling Recess Kit 2620235 Umbrella Mounting Kit 2620236 Tube Suspension Kit 2620237 Chain Suspension Kit 2620238 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE (S) CORRECTIVE ACTION No heat 1. Improper connection 1. Check connection to power supply Not enough heat 1. -
Page 14: Warranty
WARRANTY Platinum Electric Smart-Heating Warranty Conditions Bromic Pty Limited (‘Bromic’) warrants to the original purchaser (‘the Purchaser’) of products supplied by Bromic Heating (‘the Goods’) that the Goods will be free from defects and/or faults in materials and/or workmanship for Twelve (12) months from the date of Bromic invoice. - Page 15 19. Bromic does not warrant the Goods where the Goods were installed and/or used in conjunction with goods of a supplier other than Bromic (‘the other goods’) in such a way as to exceed the capacity and/or performance capabilities of the Goods or the other goods and denies all liability for any damage whatsoever suffered by any person arising from such use.
- Page 16 26. The manufacturer is not responsible for assuring compliance with jurisdictional codes and regulations governing sales, construction, installation and/or use of the heating products and cannot be responsible for how the product is installed or used. Before purchase and use of the product, it is the responsibility of the owner to review the product application and all applicable national and local codes and regulations governing the installation and use of such heating products and to seek advice from relevant technical persons.
