COBALT SMART-HEAT™
ELECTRIC HEATER
BY BROMIC
INSTALLATION, INSTRUCTION AND
SERVICE MANUAL
SUITABLE FOR ELECTRIC HEATER MODELS:
COBALT 2000W, COBALT 3000W, COBALT 4000W AND COBALT 6000W
IMPORTANT
!
READ THIS MANUAL CAREFULLY.
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL.KEEP
INSTRUCTION WITH APPLIANCE FOR FUTURE
REFERENCE.
Version 1.1GB
Revised: 30/07/2015
Advertisement
Table of Contents
Related Manuals for Bromic Heating COBALT SMART-HEAT 2000W
Summary of Contents for Bromic Heating COBALT SMART-HEAT 2000W
- Page 1 COBALT SMART-HEAT™ ELECTRIC HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL SUITABLE FOR ELECTRIC HEATER MODELS: COBALT 2000W, COBALT 3000W, COBALT 4000W AND COBALT 6000W IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL.KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE.
- Page 2 Email: info@bromicheating.com Web: www.bromicheating.com Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating. www.bromicheating.com...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION AND FEATURES SPECIFICATIONS HEATER INSTALLATION REMOVE PACKAGING MATERIAL INSTALLATION CLEARANCES CEILING WALL MOUNTING CHAIN SUSPENSION TUBE SUSPENSION ELECTRICAL INSTALLATION WIRING DIAGRAMS SERVICING MAINTENANCE TUBE ELEMENT REPLACEMENT REPLACEMENT PART LIST TROUBLESHOOTING www.bromicheating.com... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS INSTALLATION WARNING • IMPORTANT - Installation must be carried out by a licensed and authorised person. • Read all instructions before installing or using this heater • The installer is to ensure that the requirements of the local •... -
Page 5: Product Overview
Approval CE Approved *Heating areas are based on protected environment with mounting height of 2400mm. For unprotected and extremely cold and windy environments heating areas can be less. Please contact Bromic Heating for further advice. PRODUCT FEATURES • IPX4 water ingress protection rating. -
Page 6: Heater Installation
HEATER INSTALLATION WARNING This Heater MUST be permanently Installed and hard wired by an authorised/licenced person. Do Not perform maintenance, or carry out installation or assembly procedure while electrical power is switched on. REMOVE PACKAGING MATERIAL All packaging material must be removed from heater before installation. Remove warning note from front of heater Remove the wire cover by pulling it out... -
Page 7: Installation Clearances
HEATER INSTALLATION WARNING WARNING DO NOT MOUNT THE HEATER VERTICALLY! DO NOT MOUNT THE HEATER VERTICALLY! Heater MUST be installed so that the tube elements For outdoor installation heater must be mounted with are horizontal. Failure to do this will cause the heating face of heater angled down. -
Page 8: Ceiling Wall Mounting
HEATER INSTALLATION CONTINUED... CEILING & WALL MOUNTING CEILING & WALL MOUNTING Mounting Hole Centres & Heater Position (1) Mark mounting hole centres on ceiling or wall. 2620212 (2000W) - 2620214 (4000W) 2000W & 4000W Models Mark mounting hole centres on ceiling or wall. 3000W &... -
Page 9: Tube Suspension
HEATER INSTALLATION CONTINUED... TUBE SUSPENSION TUBE SUSPENSION (SOLD SEPARATELY) (SOLD SEPARATELY) Mounting Hole Centres & Heater Position Mark mounting hole centres on ceiling. Attach 1. Mark mounting hole centres on ceiling. 2000W & 4000W Models mounting brackets to ceiling using appropriate Attach mounting brackets to ceiling using appropriate fasteners (Not supplied). -
Page 10: Electrical Installation
ELECTRICAL INSTALLATION WARNING all connections must be made in accordance with local electrical code regulations for outdoor wiring. Only This Heater MUST be permanently Installed and hard wired by an authorised/licenced person. Do Not perform use wiring components approved for outdoor use with maintenance, or carry out installation or assembly minimum IPX4 rating. -
Page 11: Wiring Diagrams
ELECTRIC AL INSTALLATION CONTINUED... WIRING DIAGRAM EARTH 240 V AC COBALT SMART-HEAT ELECTRIC WIRE SINGLE PHASE STANDARD INSTALLATION 2000W & 3000W MODELS WARNING Junction Box 240 V AC Single Phase Heater must be permanently installed and hard wired by an authorised/licenced person. -
Page 12: Servicing
SERVICING WARNING Servicing and maintenance MUST be carried out by an authorised and licensed person only WARNING ELECTRICAL SHOCK HAZARD! Serious injury or death may occur. Disconnect from electrical supply before servicing this heater. MAINTENANCE For longest product life & to maintain product appearance mount heater under cover &... -
Page 13: Replacement Part List
REPLACEMENT PART LIST Description PART NUMBER Heater - Cobalt electric 2000W 240V - EU BH0610005 Heater - Cobalt electric 3000W 240V - EU BH0610006 Heater - Cobalt electric 4000W 240V - EU BH0610007 Heater - Cobalt electric 6000W 240V - EU BH0610008 Front cover - Cobalt electric 2000W &...
