tungsten smart-heat™
electric heater
BY BrOmic
INsTAllATION, INsTRucTION ANd
seRvIce MANuAl
SUITABLE FOR ELECTRIC HEATER MODELS:
TUNgSTEN 2000W, 3000W, 4000W- AND TUNgSTEN 6000W
IMPORTANT
READ THIS MANUAL CAREFULLY.
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL.KEEP
INSTRUCTION WITH APPLIANCE FOR FUTURE
REFERENCE.
Version 1.0 AUS
Advertisement
Table of Contents
Related Manuals for Bromic Heating Tungsten 2000W
Summary of Contents for Bromic Heating Tungsten 2000W
- Page 1 BY BrOmic INsTAllATION, INsTRucTION ANd seRvIce MANuAl SUITABLE FOR ELECTRIC HEATER MODELS: TUNgSTEN 2000W, 3000W, 4000W- AND TUNgSTEN 6000W IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL.KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE.
- Page 2 Email: info@bromicheating.com Web: www.bromicheating.com Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating. www.bromicheating.com...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION AND fEATURES SPECIfICATIONS HEATER INSTALLATION INSTALLATION CLEARANCES CEILING WALL MOUNTING CHAIN SUSPENSION ELEMENT INSTALLATION ELECTRICAL INSTALLATION SERVICING MAINTENANCE TUbE ELEMENT REPLACEMENT REPLACEMENT PART LIST TROUbLESHOOTING WARRANTY www.bromicheating.com... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINgS INSTALLATION WARNING • IMPORTANT - Installation must be carried out by a licensed and authorised person. • Read all instructions before installing or using this heater • The installer is to ensure that the requirements of the local •... -
Page 5: Product Overview
IMPORTANT NOTES AND WARNINgS CONTINUES MAINTENANCE/ REPAIR so may incur the penalties established by laws governing waste disposal. Proper differential collection, and the subsequent • Installation and repair must be carried out by a qualified & recycling, processing and environmentally compatible licenced service person only. -
Page 6: Heater Installation
HEATER INSTALLATION WARNINg WARNINg DO NOT MOUNT THE HEATER VERTICALLY! DO NOT MOUNT THE HEATER VERTICALLY! Heater MUST be installed so that the tube elements For outdoor installation heater must be mounted with are horizontal. Failure to do this will cause the heating face of heater angled down. -
Page 7: Ceiling Wall Mounting
HEATER INSTALLATION CONTINUED... ceIlING & WAll MOuNTING CEILING & WALL MOUNTING Mounting Hole Centres & Heater Position (1) Mark mounting hole centres on ceiling or wall. 2620212 (2000W) - 2620214 (4000W) 2000W & 4000W Models 1. Mark mounting hole centres on ceiling or wall. 3000W &... -
Page 8: Element Installation
ELEMENT INSTALLATION WARNINg This Heater MUST be permanently Installed and hard wired by an authorised/licenced person. Do Not perform maintenance, or carry out installation or assembly procedure while electrical power is switched on. 1. Remove the front cover from the heater. 2. - Page 9 ELEMENT INSTALLATION CONTINUED... 5. Assemble end caps at both ends of the heater with 2 self tapping screws. for 4000W & 6000W models ensure that the middle tab of the end caps are slotted behind the element support bracket. 2000W & 3000W Models 4000W &...
-
Page 10: Electrical Installation
ELECTRICAL INSTALLATION minimum IPX4 rating. for 2000W & 3000W models WARNINg the junction box has one loop of cable. Cut the loop This Heater MUST be permanently Installed and hard and use the two ends for the active and neutral con- wired by an authorised/licenced person. -
Page 11: Replacement Part List
REPLACEMENT PART LIST Description 2620212 2620213 2620214 2620215 (2000W) (3000W) (4000W) (6000W) Tube Element 2620216 2620217 2620216 2620217 front Cover 2620218 2620219 2620218 2620219 Element End Cover Set 2620221 2620221 2620222 2620222 Junction box Cover & Seal Set 2620223 2620223 2620223 2620223 Mounting bracket Set (Short) -
Page 12: Warranty
WARRANTY Tungsten Electric Smart-Heating Warranty Conditions Bromic Pty Limited (‘Bromic’) warrants to the original purchaser (‘the Purchaser’) of products supplied by Bromic Heating (‘the Goods’) that the Goods will be free from defects and/or faults in materials and/or workmanship for Twelve (12) months from the date of Bromic invoice. - Page 13 19. Bromic does not warrant the Goods where the Goods were installed and/or used in conjunction with goods of a supplier other than Bromic (‘the other goods’) in such a way as to exceed the capacity and/or performance capabilities of the Goods or the other goods and denies all liability for any damage whatsoever suffered by any person arising from such use.
