Bromic Heating PLATINUM SMART-HEAT II Series Installation, Instruction And Service Manual
Hide thumbs
Also See for PLATINUM SMART-HEAT II Series:
- Installation, instruction and service manual (11 pages) ,
- Installation, instruction and service manual (15 pages)
Table of Contents
Advertisement
Quick Links
PLATINUM SMART-HEAT™
ELECTRIC HEATER SERIES II
BY BROMIC
INSTALLATION, INSTRUCTION
AND SERVICE MANUAL
AVAILABLE IN 2300W & 3400W VERSION
!
IMPORTANT
READ THIS MANUAL CAREFULLY.
Original Instructions
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL. KEEP
INSTRUCTION WITH APPLIANCE FOR FUTURE
REFERENCE.
Version 2.6 US
Advertisement
Table of Contents
Related Manuals for Bromic Heating PLATINUM SMART-HEAT II Series
Summary of Contents for Bromic Heating PLATINUM SMART-HEAT II Series
- Page 1 PLATINUM SMART-HEAT™ ELECTRIC HEATER SERIES II BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL AVAILABLE IN 2300W & 3400W VERSION IMPORTANT READ THIS MANUAL CAREFULLY. Original Instructions SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL. KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE.
- Page 2 IMPORTANT This manual contains important information about the installation, operation, and maintenance of Platinum Smart-Heat™ Electric Heaters. Please pay close attention to the important safety information shown throughout this instruction manual. Any safety information will be accompanied by the following safety alert symbols: DANGER, WARNING, IMPORTANT...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS PRODUCT FEATURES HEATER INSTALLATION INSTRUCTIONS CEILING & WALL MOUNTING CEILING RECESS TUBE SUSPENSION ELECTRICAL INSTALLATION SERVICING TROUBLESHOOTING bromic.com/heating... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS power disconnected, and heater temperature WARNING has cooled to room temperature. IMPORTANT - Installation MUST be carried out by a licensed • Certain materials or items, when stored under or near the and authorised person. appliance, will be subjected to radiant heat and could be seriously damaged. -
Page 5: Product Overview
IMPORTANT NOTES AND WARNINGS CONTINUED service technician if you are unsure if you have a circuit breaker • Avoid physical shock & impact to the heater when handling. installed on the premises. • Do not apply any pressure on the glass surface. •... -
Page 6: Ceiling & Wall Mounting
HEATING INSTALLATION INSTRUCTIONS CEILING & WALL MOUNTING • Heaters must be installed according to the • Heaters must be away from the fourth wall. minimum installation clearances shown in these diagrams. WALL MOUNTING CEILING MOUNTING CEILING MOUNTING (FACE DOWN) (ANGLED) CEILING CEILING CEILING... - Page 7 HEATING INSTALLATION INSTRUCTIONS CONTINUED... OPTION 1 To exit the cable through the side of the wall mounting bracket, start from step 1. 1. Unscrew and remove plug-in wall bracket (a). 2. Attach extra supplied cable gland into the same hole from the outside of the bracket. Fasten in place with the metal cable gland nut from inside the bracket...
- Page 8 9. Fit the smaller cover over the heater bracket so that the slots pass over the shafts of the M6x14mm mounting screws (i). Fit the larger cover over the HEATING INSTALLATION INSTRUCTIONS CONTINUED... smaller cover in the same way from the opposite side of the bracket (j). 8.
-
Page 9: Ceiling Recess
HEATING INSTALLATION INSTRUCTIONS CONTINUED... CEILING RECESS (SOLD SEPARATELY) WARNING WARNING Instructions below are suitable for ceiling surfaces The heater must be completely protected against 0.4-1.2” thick. For ceiling surfaces thicker than 1.2” , water contact from above. contact Bromic for alternative installation options. WARNING WARNING The heater shall, under no circumstance, be covered... - Page 10 HEATING INSTALLATION INSTRUCTIONS CONTINUED... 1. Prepare ceiling cut-out with dimensions from images on P.9 to fit ceiling recess frame (a). Heater must be installed with heater surface at least 2400mm above the floor level, with 500mm clearance to the nearest wall on all sides of the heater. Minimum distances to combustibles within cavity must be according to only one of the two options shown.
-
Page 11: Tube Suspension
the 4 M5 screws and nuts provided (k). HEATING INSTALLATION INSTRUCTIONS 12. Remove the 4 M5 screws fastening the heater CONTINUED... mounting bracket to the back of the heater. Re-insert the screws with both halves of the ceiling support bracket in place and tighten firmly. -
Page 12: Electrical Installation
ELECTRICAL INSTALLATION WARNING ELECTRICAL INSTALLATION This heater MUST be permanently installed by 1. Check product label for correct voltage and wattage to an authorised/licenced person. Do not perform ensure sure power source conforms to the heaters maintenance, or carry out installation or assembly requirements.
