Summary of Contents for Bromic Heating PLATINUM SMART-HEAT 2200W
- Page 1 PLATINUM SMART-HEAT™ ELECTRIC HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL AVAILABLE IN 2200W VERSION IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL.KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE. Version 1.0 AUS...
- Page 2 IMPORTANT This manual contains important information about the installation, operation, and maintenance of Platinum Smart-Heat™ Electric Heaters. Please pay close attention to the important safety information shown throughout this instruction manual. Any safety information will be accompanied by the following safety alert symbols: DANGER, WARNING, IMPORTANT...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS PRODUCT FEATURES HEATER INSTALLATION INSTRUCTIONS CEILING & WALL MOUNTING CEILING RECESS TUBE SUSPENSION ELECTRICAL INSTALLATION SERVICING TROUBLESHOOTING WARRANTY www.bromicheating.com... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS & licenced service person only. The heater should be WARNING inspected before use and at least annually serviced & inspected by a qualified & licenced service person. • IMPORTANT - Installation MUST be carried out by a •... -
Page 5: Product Overview
IMPORTANT NOTES AND WARNINGS CONTINUED • In case of direct connection to a supply line, a bipolar circuit • If the supply cord is damaged, it must be replaced by breaker with contact opening distance of at least 3mm an authorised and licenced person in order to avoid a must be fitted upstream from the supply line. -
Page 6: Heater Installation Instructions
HEATING INSTALLATION INSTRUCTIONS CEILING & WALL MOUNTING • Heater must be installed with the minimum installation • Minimum distance from edge of the heater to any clearances shown in diagram. adjacent walls must be at least 250mm. Heater must be •... - Page 7 HEATING INSTALLATION INSTRUCTIONS CONTINUED... OPTION 1 To exit the cable through the side of the wall mounting bracket, start from step 1. OPTION 2 To exit the cable through the wall bracket directly into your ceiling or wall cavity, start from step 3. 1.
- Page 8 HEATING INSTALLATION INSTRUCTIONS CONTINUED... 8. To fix heater at desired angle, fully insert M4x10mm positioning screws on both sides of mounting bracket whilst holding heater in the desired position (h). The heater can positioned straight, or be angled 30deg either way. 9.
- Page 9 HEATING INSTALLATION INSTRUCTIONS CONTINUED... CEILING RECESS (SOLD SEPARATELY) WARNING Minimum vertical ceiling space clearance measured from WARNING ceiling surface must be 300mm. Instructions below are suitable for ceiling surfaces 10- Minimum horizontal ceiling space clearance measured 30mm thick. For ceiling surfaces from each edge of ceiling cut out must be 500mm.
-
Page 10: Ceiling Recess
11. Attach the bracket end-cap to the wall bracket using the 4 M5 screws and nuts provided (k). HEATING INSTALLATION INSTRUCTIONS 12. Remove the 4 M5 screws fastening the heater CONTINUED... mounting bracket to the back of the heater. Re-insert the screws with both halves of the ceiling support bracket in place and tighten firmly. -
Page 11: Electrical Installation
ELECTRICAL INSTALLATION WARNING ELECTRICAL INSTALLATION This heater MUST be permanently installed by Check product label for correct voltage and wattage an authorised/licenced person. Do not perform - Make sure power source conforms to the heaters maintenance, or carry out installation or assembly requirements. -
Page 12: Warranty
WARRANTY Platinum Electric Smart-Heating Warranty Conditions Bromic Pty Limited (‘Bromic’) warrants to the original purchaser (‘the Purchaser’) of products supplied by Bromic Heating (‘the Goods’) that the Goods will be free from defects and/or faults in materials and/or workmanship for Twelve (12) months from the date of Bromic invoice. - Page 13 19. Bromic does not warrant the Goods where the Goods were installed and/or used in conjunction with goods of a supplier other than Bromic (‘the other goods’) in such a way as to exceed the capacity and/or performance capabilities of the Goods or the other goods and denies all liability for any damage whatsoever suffered by any person arising from such use.
- Page 14 26. The manufacturer is not responsible for assuring compliance with jurisdictional codes and regulations governing sales, construction, installation and/or use of the heating products and cannot be responsible for how the product is installed or used. Before purchase and use of the product, it is the responsibility of the owner to review the product application and all applicable national and local codes and regulations governing the installation and use of such heating products and to seek advice from relevant technical persons.
