Altronix eBridge4CR Installation Manual page 3

Single IP camera shown with composite video option:
Fig. 2
eBridge4CR
To
DVR
NVR Network
Video Server
(Head End
Equipment)
Up to
100m
Ethernet Switch
Fig. 3
NVR Network
Video Server
(Head End
Equipment)
Ethernet Switch
eBridge4CR
Composite
Video Cables
Coax
Structured Cable
Composite
Video Cable
eBridge4CR
Up to
100m
eBridge1CT
Up to
500m
eBridge1CT
Up to
500m
eBridge1CT
Up to
500m
eBridge1CT
Up to
500m
Up to 500m
IP Camera
Comp. Video
(external power
Cable
required).
Up to 100m
Comp. Video
IP Camera
Cable
(external power
required).
Up to 100m
Comp. Video
IP Camera
Cable
(external power
required).
Up to 100m
Comp. Video
IP Camera
Cable
(external power
required).
Up to 100m
IP Camera
Hybrid w/Sloc Technology
(external power required).
Coax
Structured Cable
- 3 -
