Altronix eBridge PLUS eBridge100SPR Installation Manual

Altronix eBridge100SPR passes data and sends power over the coax to eBridge200WPMT. Data transmission and
power over the Coax is possible up to 300m. Maximum range from headend to the PoE camera/device is 500m,
taking into consideration that up to 100m of structured cable may be deployed at each end. Built in IP management
allows for remote camera reset, monitoring, and reporting via various IP protocols.
Note: Ethernet maximum distance (see Maximum Length of Coax Type vs. Camera Power/PoE Class, pg. 3).
Agency Listings:
• UL/cUL Listed for Information
Technology Equipment (UL 60950-1).
• CE European Conformity.
Input:
• 51-56VDC/60W max. power.*
Power Output:
• Total output power: 60W.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair Cat-5 or better structured cable.
• Distance: up to 100m.
• Speed: 100BaseT, half/full duplex, auto negotiation.
Coax:
• Distance: up to 300m.
• Connectivity: BNC, RG-59/U or similar.
• Throughput is rated to pass 100Mbps from camera
to receiver. Data distances of up to 300m can be
achieved. With the proper headend equipment
multiple Megapixel cameras can be used.
*UL Listed Class 2 or limited power source.
eBridge100SPR
EoC Receiver
Installation Guide
PLUS
Overview:
Features:
LED Indicators:
• Blue LED - Coax link connection.
• Green LED - Power.
• Yellow and Green LED (RJ45) IP Link status,
100Base-T/active.
Environmental:
• Operating temperature:
– 20ºC to 50ºC (– 4ºF to 122ºF).
• Storage temperature:
– 30ºC to 70ºC (– 22º to 158ºF).
• Humidity: 20 to 85%, non-condensing.
Applications:
• Works with Megapixel, HD720, HD1080 and
VGA (SD) cameras (see note, pg. 2).
• Extend Network link distance in an industrial
environment.
• Upgrade deployed CCTV Coax to a digital network
in Retail, Hospitality, Arenas, Casinos, Airports,
Schools, Hospitals, Transportation, etc.
Mechanical:
• Dimensions (W x L x H approx.):
3.5" x 4.375" x 1" (88.9mm x 111.1mm x 25.4mm).
I.T.E. 43KC
