Page 1: Installation Guide
IP over Coax Receiver Installation Guide Models Include: eBridge8PCRX - Eight (8) Channel Receiver I.T.E. 43KC More than just power.™ Rev. 072412... -
Page 2: Installation Instructions
15.4W (PoE) or eBridge1PCTX 30W (PoE+) transmitter under PoE protocol. The eBridge1PCT/PCTX in turn delivers that power to a PoE enabled camera or IP device. The eBridge8PCRX will not deliver power to non com- pliant devices, thus avoiding accidental power turn into improperly connected analog cameras. These plug and play units facilitate system upgrades from analog to IP cameras/devices utilizing existing legacy Coax and eliminating the costs and labor associated with installing new network cabling. -
Page 3: Technical Specifications
1. Attach mounting brackets to eBridge8PCRX unit for rack installation (Fig. 5, pg. 8). Affix rubber pads to eBridge8PCRX for shelf installation (Fig. 6, pg. 8). 2. Unit should be located in proximity to ethernet switch/network, NVR or video server. - Page 4 239.3 365.8 365.8 eBridge8PCRX User Interface and Programming: Note: A constant PC connection is not required for proper operations and is used as a local programming/monitoring tool only. Step 1. Set Local Area Connection of your laptop to DHCP mode.
-
Page 5: Network Type
It is strongly recommended that you connect via host name when units configured as DHCP. Please do not set the DHCP address issued to the eBridge8PCRX by the router as its static IP address unless you take specific steps that program your router to prevent such address conflicts. -
Page 6: Reset Features
ISPs BLOCK traffic using port 80 from reaching the average site. If you only plan to monitor your eBridge8PCRX on a LAN, you can use port 80, and don’t have to concern yourself with routers. - Page 7 Rack Mount Chassis Mechanical Drawing & Dimensions: 1.625” x 19.125” x 8.5” (42mm x 486mm x 216mm) Fig. 4 19.125" 486mm 0.75" 19.05mm 17.625" 447.7mm 8.5" 216mm 1.625" 42mm eBridge8PCRX - 7 -...
-
Page 8: Mounting Options
Four (4) rubber pads. Rubber Pad Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. MEMBER IIeBridge8PCRX H04N - 8 -...
