- Page 1 T5-series Panel PC Intel Core Duo Mini-ITX SBC, Low Power, High Performance Design with Intel Platform, TFT LCD and 10/100/1000 base-T Ethernet. User Guide Version 1.2...
-
Page 2: Fcc Statement
FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions： This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "a" digital device, pursuant to part 15 of the FCC rules. -
Page 3: Copyright Notice
If the customer discovers a defect, Winmate will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid. -
Page 4: Check List
Customer Service We provide service guide for any problem as follow steps：First, visit the website at http://www.winmate.com to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may have the following information ready before you call：... -
Page 5: Safety Precautions
Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. -
Page 6: Safety And Warranty
Safety and Warranty Please read these safety instructions carefully. Please keep this user's manual for later reference. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible. -
Page 7: Revision History
Revision History Version Date Note Author 2007.09.11 First Version Aladin Huang 2007.09.20 Double Check Aladin Huang 2007.10.02 H/W Double Check Kevin Chen T5 series Panel PC User Guide... -
Page 8: Table Of Contents
Contents CHAPTER 1 GENERAL INFORMATION..................1 1-1 Introduction .....................1 1-2 I370 SBC and T5 series Panel PC System Specifications.......2 1-3 LCD Selection Guide..................3 CHAPTER 2 GETTING STARTED.....................4 2-1 Input / Output Devices..................4 2-2 Starting the Panel PC& O/S Installation............5 2-3 Driver Installation....................5 CHAPTER 3 TOUCH DRIVER INSTALLATION................6 3-1 Introduction .....................6 3-2 The ELO AccuTouch Driver Installation............7... -
Page 9: Chapter 1 General Information
Chapter 1 GENERAL INFORMATION 1-1 Introduction The T5 series Panel PC is high performance, low power PC with Intel 945 GME chipset combine with a TFT LCD Panel. The Intel Core Duo high performance Processor delivers the most performance per watt available in the market. -
Page 10: I370 Sbc And T5 Series Panel Pc System Specifications
1-2 I370 SBC and T5 series Panel PC System Specifications Form Factor Mini-ITX Intel Core2 Duo, Core Duo, Core Solo, Celeron M ULV Processor Chipset Intel Socket M Memory 2 x DDR2 DIMM socket, supports up to 4GB DDR2 533/667 SDRAM (240 pins) BIOS Award 4Mbit VGA Controller... -
Page 11: Lcd Selection Guide
1-3 LCD Selection Guide The T5 series Panel PCs support form 10.4-inch to 20.1-inch TFT Panel w/ touchscreen function, please refer the below: Item Resolution Display Color Size (Recommended) 10.4” R10I37T-OFM3 1024x768 16.2M (6bits/color) 10.4” R10I37T-OFP1 800 x 600 262,144 (6bit/colors) 10.4”... -
Page 12: Chapter 2 Getting Started
Chapter 2 Getting Started 2-1 Input / Output Devices The following figure shows the I/O arrangement of the Panel PC. The backside of the chassis contains most of the connectors (10.4” for example). Power Jack (Optional) Heater board (Optional) Reset Power Reset bottom to reset your PPC. -
Page 13: Starting The Panel Pc& O/S Installation
2-2 Starting the Panel PC& O/S Installation Connect the power to AC/DC adapter, and connect the power cord to the AC outlet. Press the power on switch to start the Panel PC. Press “DEL” to enter the CMOS setting and check the BIOS setup. You may install your own O/S if it is not installed. -
Page 14: Chapter 3 Touch Driver Installation
Chapter 3 Touch Driver Installation 3-1 Introduction The PPC supports three kinds of Touch Panel Solutions: ELO AccuTouch touchscreen, Premier Touch system. Both of the touchscreen system consists of a touchscreen and an electronic touchscreen controller. The T5 series Panel PC’s touch device is used RS232 interface touch controller card via the COM3 port inside Panel PC. -
Page 15: The Elo Accutouch Driver Installation
3-2 The ELO AccuTouch Driver Installation ELO AccuTouch driver software provides a consistent software interface among all ELO AccuTouch touch screens and controllers. Go to http://www.elotouch.com/Support/dnld.asp for a complete list of available drivers. For Driver Installation, please install the “ELO Touch System Touch Tools CD” for Windows XP, Windows 2000, Windows Me, Windows 98, Windows 95, Windows NT, Windows CE 2.x, 3.0, 4.x, Windows XP Embedded, Windows 3.1, DOS, OS/2 Warp, and Apple Macintosh. -
Page 16: Configuration Utility
3-2-1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Enter “My Computer”, click the “Elo touchscreen” shortcut function. Step.2 Click “Align” function key to go to next step. T5 series Panel PC User Guide... - Page 17 Step.3 Correct 4 point locations on screen with the Panel PC. Screen display as follows. Step.4 Touch the “yes” function if the cursor follows your finger and finish the utility test. T5 series Panel PC User Guide...
-
Page 18: The Premier Touch Driver Installation
3-3 The Premier Touch Driver Installation TouchKit is the Premier Touch software, which contains drivers of the touch panel controllers for the specified communication connectors, RS232, PS/2 and USB, and the other two utilities. The two utilities are as follows: Touch Tray support This is utility for emulating the right and left button of mouse through controlling touch panel. -
Page 19: Configuration Utility
3-3-1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Click the “TouchKit” shortcut function in the desktop. Step.2 Enter “General” function and choose the language you need. Then go to next step. T5 series Panel PC User Guide... - Page 20 Step.3 Correct 4 point locations on screen with the Panel. Screen display as follows Step.4 Play “Yes” to continue if 4 points calibration test is fine and finish the test. T5 series Panel PC User Guide...
-
Page 21: Chapter 4 T5 Series Panel Pc Mounting Guide
Chapter 4 T5 series Panel PC Mounting Guide The Panel PC is suitable for most of the industrial/commercial application, by any kind of mounting approach. Three main mounting approaches, such as Panel Mount / Chassis / Open Frame, are very easy for user to install the Panel PC. - Page 22 Panel PC size VESA Mount Dimension Panel PC size VESA Mount Dimension 75 x 75 mm / 8.4” 75 x 75 mm 17” 100 x 100 mm 75 x 75 mm / 10.4” 75 x 75 mm 19” 100 x 100 mm T5 series Panel PC User Guide...
-
Page 23: 5Mm Panel Mount Panel Pc
4-2 5mm Panel Mount Panel PC: -Panel is aligned with the same height of the front of open frame metal housing. -Touch/Glass is higher than Open frame metal housing. -Customers can fix our Panel PC with their fixture (max.12mm) -VESA mount holes are also available for mounting from back side. T5 series Panel PC User Guide... - Page 24 ( note : Not support 6.4” and 6.5” ) T5 series Panel PC User Guide...
-
Page 25: 10Mm Ip65 Panel Pc
4-3 10mm IP65 Panel PC -Touch/Glass is aligned with the same height of the front of open frame metal housing -Customers can fix our Panel PC with their fixture by M3 screws. -VESA mount holes are also available for mounting from back side. T5 series Panel PC User Guide... - Page 26 T5 series Panel PC User Guide...
-
Page 27: Chassis Panel Pc
4-4 Chassis Panel PC Fix the Panel PC with four screws (standard VESA), and fasten to the wall with other four screws. - 100 x 100 mm - 75 x 75 mm Panel PC size VESA Mount Dimension Panel PC size VESA Mount Dimension 6.4”... -
Page 28: Known Issues
KNOWN ISSUES There might be some image noises displayed at the time of PC boot and Windows start up. When using an “external display” as CRT or LCD for external mode (Panel & CRT), the resolution of external display may be recommended equal to the CMOS setting for panel [Flat Panel Type]. -
Page 29: Notices
NOTICES 1. The Operation Systems we currently support are Windows XP and XP Embedded. When installing driver, please make sure you’re using Windows XP Service Package2 (SP2) above. 2. The VGA output port for I370 is only for displaying the same images as built-in display.
