IC70-series Panel PC
Intel® i5/i7 800/1066 MHz Mini-ITX SBC,
High Performance Design with Intel
HM55 Platform, CRT/LCD/TV and
versatile expansions.
User Guide Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC70 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate IC70 series

Summary of Contents for Winmate IC70 series

  • Page 1 IC70-series Panel PC Intel® i5/i7 800/1066 MHz Mini-ITX SBC, High Performance Design with Intel HM55 Platform, CRT/LCD/TV and versatile expansions. User Guide Version 1.0...

  • Page 2: Fcc Statement

    Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. IC70 series Panel PC User Guide...

  • Page 3: Copyright Notice

    (e. g., with A for October, B for November and C for December). For example, the serial number 1W07Axxxxxxxx means October of year 2007. IC70 series Panel PC User Guide...
  • Page 4 Before using this Panel PC, please make sure that all the items listed below are present in your package 1 x IC70 series Panel PC 1 x IC70 series Panel PC User Guide 1 x IC70 SBC User Manual 1 x Power adapter 1 x CD-ROM disc with Driver Utility and User's Manual Make sure that all of the items listed above are present.

  • Page 5: Safety Precautions

    As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. IC70 series Panel PC User Guide...

  • Page 6: Safety And Warranty

    F. The equipment has obvious signs of breakage. 15. Do not leave this equipment in an uncontrolled environment where the storage temperature is below -20° C (-4°F) or above 60° C (140° F). It may damage the equipment. IC70 series Panel PC User Guide...
  • Page 7 Revision History Version Date Note Author 2011.08.16 First Version Henry Hsu IC70 series Panel PC User Guide...

  • Page 8: Table Of Contents

    3-2-1 Configuration Utility ................ 8 3-3 The Premier Touch Driver Installation ............10 3-3-1 Configuration Utility ...............11 CHAPTER 4 IC70 SERIES PANEL PC MOUNTING GUIDE ............13 4-1 Open Frame Panel PC:................13 4-2 5mm Panel Mount Panel PC: ..............15 4-3 10mm IP65 Panel PC.................

  • Page 9: Chapter 1 General Information

    Chapter 1 GENERAL INFORMATION 1-1 Introduction ® The IC70 series Panel PC is high performance PC with Intel HM55 chipset ® which combines with a TFT LCD Panel. The Intel i5/i7 high performance Processor delivers the most performance per watt available in the market. The...

  • Page 10: Ic70 Series Panel Pc System Specifications

    1-2 IC70 series Panel PC System Specifications Form Factor Mini-ITX 800/1066 MHz Intel® i5/i7 Processor Chipset HM55 Memory DDR3 1066/800MHz SO-DIMM x 2 Slot (MAX 8GB) BIOS AMI UEFI BIOS Graphic Controller Integrated Gfx Gen5.75 Up to 2048 x 1536 @ 75Hz...

  • Page 11: Lcd Selection Guide

    1-3 LCD Selection Guide The IC70 series Panel PCs support form 10.4-inch to 15-inch TFT Panel w/ touchscreen function, please refer the below: Item Resolution Display Color Size (Recommended) 15” R15IC7T-XXC3 1024 x 768 16.2M colors (RGB 8-bits). 15” R15IC7T-XXA1 1024 x 768 16.2M colors (RGB 8-bits).

  • Page 12: Chapter 2 Getting Started

    VGA port Use VGA port to connect an external Display. COM port Two RS-232 connectors build in the rear I/O. The Motherboard provides two PS/2 interface. The PS/2 PS/2 connector supports Keyboard (Green) and Mouse. IC70 series Panel PC User Guide...

  • Page 13: Starting The Panel Pc& O/S Installation

    Manual Chapter 3, 4, 5, 6) include: Chipset, VGA, Audio, and Ethernet. 2. Following the step by step to install the Touch screen if necessary (Please refer T series PPC User Guide Chapter 3). IC70 series Panel PC User Guide...

  • Page 14: Chapter 3 Touch Driver Installation

    Premier Touch system. Both of the touchscreen system consists of a touchscreen and an electronic touchscreen controller. The IC70 series Panel PC’s touch device is used RS232 interface touch controller card via the COM2 port inside Panel PC. When the touch driver installed either for ELO or Premier Touch systems, it will detect COM2 port automatically.

  • Page 15: The Elo Accutouch Driver Installation

    Apple Macintosh. Just follow the step by step to install the driver. Choose “Auto-detect Elo devices ” in the first step. If not, the following step will need users choose COM2 port for detecting the devices. IC70 series Panel PC User Guide...

  • Page 16: Configuration Utility

    3-2-1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Enter “My Computer”, click the “Elo touchscreen” shortcut function. Step.2 Click “Align” function key to go to next step. IC70 series Panel PC User Guide...
  • Page 17 Step.3 Correct 4 point locations on screen with the Panel PC. Screen display as follows. Step.4 Touch the “yes” function if the cursor follows your finger and finish the utility test. IC70 series Panel PC User Guide...

  • Page 18: The Premier Touch Driver Installation

    Notice that does not plug the USB controller on the system before the installation has been finished. Step.4 Click Next to continue installation. And it will auto-detect touch devices in COM1 port at your Panel PC. Step.5 Following the step by step to finish the driver installation. IC70 series Panel PC User Guide...

  • Page 19: Configuration Utility

    After finishing the installation, please follow the steps to test the configuration utility. Step.1 Click the “TouchKit” shortcut function in the desktop. Step.2 Enter “General” function and choose the language you need. Then go to next step. IC70 series Panel PC User Guide...
  • Page 20 Step.3 Correct 4 point locations on screen with the Panel. Screen display as follows Step.4 Play “Yes” to continue if 4 points calibration test is fine and finish the test. IC70 series Panel PC User Guide...

  • Page 21: Chapter 4 Ic70 Series Panel Pc Mounting Guide

    Chapter 4 IC70 series Panel PC Mounting Guide The Panel PC is suitable for most of the industrial/commercial application, by any kind of mounting approach. Three main mounting approaches, such as Panel Mount / Chassis / Open Frame, are very easy for user to install the Panel PC.
  • Page 22 Panel PC size VESA Mount Dimension 75 x 75 mm / 15” 100 x 100 mm 75 x 75 mm / 17” 100 x 100 mm 75 x 75 mm / 19” 100 x 100 mm IC70 series Panel PC User Guide...

  • Page 23: 5Mm Panel Mount Panel Pc

    -Panel is aligned with the same height of the front of open frame metal housing. -Touch/Glass is higher than Open frame metal housing. -Customers can fix our Panel PC with their fixture (max.12mm) -VESA mount holes are also available for mounting from back side. IC70 series Panel PC User Guide...
  • Page 24 IC70 series Panel PC User Guide...

  • Page 25: 10Mm Ip65 Panel Pc

    -Touch/Glass is aligned with the same height of the front of open frame metal housing -Customers can fix our Panel PC with their fixture by M3 screws. -VESA mount holes are also available for mounting from back side. IC70 series Panel PC User Guide...
  • Page 26 IC70 series Panel PC User Guide...

  • Page 27: Chassis Panel Pc

    Panel PC size VESA Mount Dimension 75 x 75 mm / 15” 100 x 100 mm 75 x 75 mm / 17” 100 x 100 mm 75 x 75 mm / 19” 100 x 100 mm IC70 series Panel PC User Guide...
