NANO-PV-D4251/N4551/D5251 EPIC SBC
IEI Technology Corp.
MODEL:
NANO-PV-D4251/N4551/D5251
EPIC Motherboard with Intel® Atom™ processor
D525/D425/N455, VGA, LVDS, GbE LAN, Eight USB 2.0, Two
SATA 3Gb/s, Three RS-232, RS-232/422/485, PCIe mini, PCI-104,
Rev. 1.03 - 3 September, 2012
)zNANO-PV-D4251/N4551/D5251 CPU Card
Parallel port, RoHS

User Manual

Page I

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology Nano-PV-D4251

Summary of Contents for IEI Technology Nano-PV-D4251

  • Page 1: User Manual

    NANO-PV-D4251/N4551/D5251 EPIC SBC )zNANO-PV-D4251/N4551/D5251 CPU Card IEI Technology Corp. MODEL: NANO-PV-D4251/N4551/D5251 EPIC Motherboard with Intel® Atom™ processor D525/D425/N455, VGA, LVDS, GbE LAN, Eight USB 2.0, Two SATA 3Gb/s, Three RS-232, RS-232/422/485, PCIe mini, PCI-104, Parallel port, RoHS User Manual Page I...
  • Page 2 NANO-PV-D4251/N4551/D5251 EPIC SBC Revision Date Version Changes 3 September, 2012 1.03 Updated Table 3-13: Parallel Port Connector Pinouts 4 November, 2011 1.02 Minor update to Table 3 16: CPU 12V Power Connector Pinouts 26 August, 2011 1.01 Updated Section 4.5.8 LVDS1 Screen Resolution Selection 11 October, 2010 1.00...
  • Page 3 NANO-PV-D4251/N4551/D5251 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    ACKING 2.3.1 Optional Items....................12 3 CONNECTORS ......................13 3.1 P ..............14 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-PV-D4251/N4551/D5251 Layout............14 3.1.2 Peripheral Interface Connectors ..............15 3.1.3 External Interface Panel Connectors............... 16 3.2 I ..............16 NTERNAL ERIPHERAL ONNECTORS 3.2.1 Audio Connector ....................17 3.2.2 Battery Connector....................
  • Page 5 NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.13 PCIe Mini Card Slot ..................27 3.2.14 12V Power Connector..................29 3.2.15 SATA Drive Connectors ................. 29 3.2.16 SATA Power Connector.................. 30 3.2.17 Serial Port Connectors (RS-232) ..............31 3.2.18 Serial Port Connector (RS-232/422/485) ............32 3.2.19 SMBus Connector ..................
  • Page 6 NANO-PV-D4251/N4551/D5251 EPIC SBC 4.6.1 Airflow......................53 4.6.2 Motherboard Installation................. 54 4.7 I ............54 NTERNAL ERIPHERAL EVICE ONNECTIONS 4.7.1 AT/ATX Power Connection ................54 4.7.2 Audio Kit Installation..................56 4.7.3 Single RS-232 Cable (w/o Bracket) ..............57 4.8 E ........... 58...
  • Page 7 NANO-PV-D4251/N4551/D5251 EPIC SBC 5.4.1 Host Bridge Configuration ................88 5.4.1.1 OnChip VGA Configuration ..............89 5.4.2 South Bridge Configuration................90 5.4.3 Intel IGD SWSCI OpRegion................91 5.5 B ........................93 5.6 S ......................... 94 ECURITY 5.7 E ......................... 96 A BIOS MENU OPTIONS ..................... 98 B ONE KEY RECOVERY ...................
  • Page 8 Figure 3-21: SPI Flash Connector ....................33 Figure 3-22: TPM Connector Pinout Locations .................34 Figure 3-23: USB Connector Pinout Locations .................35 Figure 3-24: NANO-PV-D4251/N4551/D5251 External Peripheral Interface Connector ..36 Figure 3-25: RJ-45 Ethernet Connector..................37 Figure 3-26: PS/2 Pinout and Configuration ................38 Figure 3-27: VGA Connector .......................39...
  • Page 9 NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-1: SO-DIMM Installation ....................44 Figure 4-2: AT Auto Button Select Jumper Settings..............46 Figure 4-3: AT/ATX Power Select Jumper Location..............46 Figure 4-4: Clear CMOS Jumper ....................48 Figure 4-5: COM 3 Function Select Jumper Location...............48 Figure 4-6: COM 3 RS-422/485 Function Select Jumper Location ..........49 Figure 4-7: CompactFlash®...
  • Page 10 NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-14: Select a Local Source Drive ................114 Figure B-15: Select a Source Partition from Basic Drive ............114 Figure B-16: File Name to Copy Image to ................115 Figure B-17: Compress Image....................115 Figure B-18: Image Creation Confirmation ................116 Figure B-19: Image Creation Complete ...................
  • Page 11 NANO-PV-D4251/N4551/D5251 EPIC SBC List of Tables Table 1-1: Technical Specifications....................8 Table 3-1: Peripheral Interface Connectors ................16 Table 3-2: Rear Panel Connectors ....................16 Table 3-3: Audio Connector Pinouts ..................17 Table 3-4: Battery Connector Pinouts ..................18 Table 3-5: CompactFlash® Slot Pinouts ..................19 Table 3-6: Digital I/O Connector Pinouts..................20...
  • Page 12 NANO-PV-D4251/N4551/D5251 EPIC SBC Table 4-2: AT Auto Button Power Select Jumper Settings ............45 Table 4-3: AT/ATX Power Select Jumper Settings ..............46 Table 4-4: Clear CMOS Jumper Settings..................47 Table 4-5: COM 3 Function Select Jumper Settings ..............48 Table 4-6: COM 3 RS-422/485 Function Select Jumper Settings..........49 Table 4-7: CompactFlash®...
  • Page 13 NANO-PV-D4251/N4551/D5251 EPIC SBC List of BIOS Menus BIOS Menu 1: Main ........................69 BIOS Menu 2: Advanced ......................70 BIOS Menu 3: ACPI Settings .......................71 BIOS Menu 4: TPM Configuration ....................72 BIOS Menu 5: CPU Configuration ....................73 BIOS Menu 6: IDE Configuration....................74 BIOS Menu 7: USB Configuration ....................75...

  • Page 14: Introduction

    NANO-PV-D4251/N4551/D5251 EPIC SBC Chapter Introduction Page 1...

  • Page 15: Introduction

    (with support). NANO-PV-D4251/N4551/D5251 also supports two SATA 3Gb/s drives and provides 5 V SATA power. The NANO-PV-D4251/N4551/D5251 supports dual display via VGA and an internal LVDS LCD connector. Eight USB 2.0 channels, one PCIe mini socket, one PCI-104 slot and internal one parallel port connector provide flexible expansion options.

  • Page 16: Figure 1-2: Connectors

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 1-2: Connectors Page 3...

  • Page 17: Dimensions

    NANO-PV-D4251/N4551/D5251 EPIC SBC 1.3 Dimensions The dimensions of the board are listed below: Length: 165 mm Width: 115 mm Figure 1-3: NANO-PV-D4251/N4551/D5251 Dimensions (mm) Page 4...

  • Page 18: Data Flow

    NANO-PV-D4251/N4551/D5251 EPIC SBC 1.4 Data Flow F igure 1-4 shows the data flow between the two on-board chipsets and other components installed on the motherboard and described in the following sections of this chapter. Figure 1-4: Data Flow Block Diagram...

  • Page 19: Technical Specifications

    NANO-PV-D4251/N4551/D5251 EPIC SBC 1.5 Technical Specifications NANO-PV-D4251/N4551/D5251 technical specifications are listed in table below. Specification NANO-PV-D4251/N4551/D5251 EPIC Form Factor Intel® Atom™ processor D525, 1.8 GHz/1 MB L2 cache CPU options Intel® Atom™ processor D425, 1.8 GHz/512 KB L2 cache Intel® Atom™ processor N455, 1.66 GHz/512 KB L2 cache Intel®...
  • Page 20 NANO-PV-D4251/N4551/D5251 EPIC SBC Specification NANO-PV-D4251/N4551/D5251 Display Ports One VGA port (up to 2048x1536 for D4251/D5251, up to 1400x1050 for N4551) One internal 18-bit single-channel LVDS connector (up to 1024 x 768 or 1366 x 768) Two RJ-45 GbE ports Ethernet...

  • Page 21: Table 1-1: Technical Specifications

    NANO-PV-D4251/N4551/D5251 EPIC SBC Specification NANO-PV-D4251/N4551/D5251 165 mm x 115 mm Dimensions Weight GW/NW 670 g / 350 g Table 1-1: Technical Specifications Page 8...

  • Page 22: Unpacking

    NANO-PV-D4251/N4551/D5251 EPIC SBC Chapter Unpacking Page 9...

  • Page 23: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the NANO-PV-D4251/N4551/D5251 is unpacked, please do the following: Follow the antistatic guidelines above. Make sure the packing box is facing upwards when opening.

  • Page 24: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-PV-D4251/N4551/D5251 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 25: Optional Items

    NANO-PV-D4251/N4551/D5251 EPIC SBC Mini jumper pack (2.0mm) (P/N: 33100-000033-RS) Utility CD Quick Installation Guide 2.3.1 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image LPT cable (wo bracket) (P/N: 32200-015100-RS) RS-232/422/485 cable...

  • Page 26: Connectors

    NANO-PV-D4251/N4551/D5251 EPIC SBC Chapter Connectors Page 13...

  • Page 27: Peripheral Interface Connectors

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 NANO-PV-D4251/N4551/D5251 Layout The figures below show all the connectors and jumpers. Figure 3-1: Connector and Jumper Locations Page 14...

  • Page 28: Peripheral Interface Connectors

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label Audio connector 10-pin header AUDIO1 Battery connector 2-pin wafer BAT1 CompactFlash® slot 50-pin header DDR3 SO-DIMM socket 204-pin socket DIMM1...

  • Page 29: External Interface Panel Connectors

    VGA port connector 15-pin Female VGA1 Serial port (RS-232) connector 9-pin male COM1 USB ports (dual) USB port USB6_7 Table 3-2: Rear Panel Connectors 3.2 Internal Peripheral Connectors The section describes all of the connectors on the NANO-PV-D4251/N4551/D5251. Page 16...

  • Page 30: Audio Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.1 Audio Connector CN Label: AUDIO1 CN Type: 10-pin header (2x5) CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 The audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 31: Compactflash® Slot

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 3-3: Battery Connector Location Description Battery+ Ground Table 3-4: Battery Connector Pinouts 3.2.3 CompactFlash® Slot CN Label: CompactFlash® card slot CN Type: CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 A CompactFlash® Type I/II card can be used in this slot.

  • Page 32: Digital I/O Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC Description Description DATA 7 DATA 15 HDC_CS0# HDC_CS1 GROUND IOR# IOW# VCC_COM IRQ15 VCC_COM VCC_COM CSEL HDD_RESET IORDY SDREQ SDACK# HDD_ACTIVE# DATA 0 66DET DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 VCC-IN CHECK2 GROUND Table 3-5: CompactFlash®...

  • Page 33: Fan Connector (Cpu)

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 3-5: Digital I/O Connector Locations Description Description Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-6: Digital I/O Connector Pinouts 3.2.5 Fan Connector (CPU) CN Label: CPU_FAN1...

  • Page 34: Fan Connector (System)

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.6 Fan Connector (System) CN Label: SYS_FAN1 CN Type: 3-pin wafer (1x3) CN Location: F igure 3-7 CN Pinouts: T able 3-8 The cooling fan connector provides a 12V, 500mA current to the cooling fan. The connector has a "rotation" pin to get rotation signals from fans and notify the system so the system BIOS can recognize the fan speed.

  • Page 35: Keyboard/Mouse Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC The front panel connector connects to external switches and indicators to monitor and controls the motherboard. These indicators and switches include: Power button Reset Power LED HDD LED Figure 3-8: Front Panel Connector Location FUNCTION DESCRIPTION FUNCTION...

  • Page 36: Backlight Inverter Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 3-9: Keyboard/Mouse Connector Location Description +5 VCC MS DATA MS CLK KB DATA KB CLK GROUND Table 3-10: Keyboard/Mouse Connector Pinouts 3.2.9 Backlight Inverter Connector CN Label: INV1 CN Type: 5-pin wafer (1x5) CN Location: See Figure 3-10...

  • Page 37: Lvds1 Lcd Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC Description BACKLIGHT ENABLE Table 3-11: Backlight Inverter Connector Pinouts 3.2.10 LVDS1 LCD Connector CN Label: LVDS1 CN Type: 20-pin crimp (2x10) CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 The LVDS1 connector is for an LCD panel connected to the board.

  • Page 38: Parallel Port Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.11 Parallel Port Connector CN Label: LPT1 26-pin box header CN Type: CN Location: See Figure 3-12 CN Pinouts: See Table 3-13 The parallel port connector connects to a parallel port connector interface or some other parallel port device such as a printer.

  • Page 39: Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.12 PCI-104 Connector CN Label: PCI-104_PLUS1 PCI-104 connector CN Type: CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 The PCI-104 connector is for installing a PCI-104 expansion card. Figure 3-13: PCI-104 Connector Location Row A...

  • Page 40: Pcie Mini Card Slot

    NANO-PV-D4251/N4551/D5251 EPIC SBC Row A Row B Row C Row D +3.3 V AD23 AD22 +3.3 V IDSEL0 IDSEL1 IDSEL2 AD24 C/BE3# VI/O1 IDSEL3 AD26 AD25 AD29 +5 V AD28 AD27 +5 V AD30 AD31 REQ0# REQ1# VI/O2 REQ2# +5 V...

  • Page 41: Table 3-15: Pcie Mini Card Slot Pinouts

    NANO-PV-D4251/N4551/D5251 EPIC SBC Description Description PCIE_WAKE# VCC3 1.5 V CLKREQ# LFRAME# LAD3 CLK- LAD2 CLK+ LAD1 LAD0 PCIRST# VCC3 PCIRST# PERN2 3VDual PERP2 1.5 V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ VCC3 VCC3 RF_LINK# SATATXP2/CL_CLK BLUELED# SATATXN2/CL_DATA 1.5 V SATARXN2/CL_RST#...

  • Page 42: Power Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.2.14 12V Power Connector CN Label: CPU12V1 CN Type: 4-pin Molex power connector (1x4) CN Location: See Figure 3-15 CN Pinouts: See Table 3-16 The connector supports the 12V power supply. Figure 3-15: CPU 12V Power Connector Location PIN NO.

  • Page 43: Sata Power Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 3-16: SATA Drive Connector Locations PIN NO. DESCRIPTION Table 3-17: SATA Drive Connector Pinouts 3.2.16 SATA Power Connector CN Label: PWR1 2-pin wafer (1x2) CN Type: CN Location: See Figure 3-17 CN Pinouts: See Table 3-18 The SATA Power Connector provides +5V power output to the SATA connectors.

  • Page 44: Serial Port Connectors (Rs-232)

    NANO-PV-D4251/N4551/D5251 EPIC SBC PIN NO. DESCRIPTION Table 3-18: SATA Power Connector Pinouts 3.2.17 Serial Port Connectors (RS-232) CN Label: COM2, COM4, COM5 CN Type: 10-pin header (2x5) CN Location: F igure 3-18 CN Pinouts: T able 3-19 These connectors provide RS-232 communications.

  • Page 45: Serial Port Connector (Rs-232/422/485)

    NANO-PV-D4251/N4551/D5251 EPIC SBC Ground (GND) Table 3-19: COM Connector Pinouts 3.2.18 Serial Port Connector (RS-232/422/485) CN Label: COM3 CN Type: 14-pin header (2x7) CN Location: See Figure 3-19 CN Pinouts: See Table 3-20 Used for RS-232/422/485 communications. Figure 3-19: Serial Port Connector Location PIN NO.

  • Page 46: Spi Flash Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC The SMBus Connector provides a connection to a SMBus (System Management Bus) device. Figure 3-20: SMBus Connector Locations PIN NO. DESCRIPTION SMBDATA SMBCLK VCC5S Table 3-21: SMBus Connector Pinouts 3.2.20 SPI Flash Connector CN Label: SPI1 CN Type:...

  • Page 47: Tpm Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC Description Description CLOCK Table 3-22: SPI Flash Connector Pinouts 3.2.21 TPM Connector CN Label: TPM1 20-pin header (2x10) CN Type: CN Location: See Figure 3-22 CN Pinouts: See Table 3-23 The Trusted Platform Module (TPM) connector secures the system on bootup.

  • Page 48: Usb Connectors

    NANO-PV-D4251/N4551/D5251 EPIC SBC PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC3S LDRQ# Table 3-23: TPM Connector Pinouts 3.2.22 USB Connectors CN Label: USB0_1, USB2_3, USB4_5 CN Type: 8-pin header (2x4) CN Location: See Figure 3-23 CN Pinouts: See Table 3-28 The USB connectors connect to USB devices. Each pin header provides two USB ports.

  • Page 49: External Peripheral Interface Connector Panel

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.3 External Peripheral Interface Connector Panel F igure 3-24 shows the NANO-PV-D4251/N4551/D5251 external peripheral interface connector (EPIC) panel. The NANO-PV-D4251/N4551/D5251 EPIC panel consists of the following: 1 x Ethernet connector 1 x Keyboard/Mouse 1 x Serial port (RS-232)

  • Page 50: Keyboard/Mouse Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC LAN1_MDI3P LAN1_MDI3N Table 3-25: LAN Pinouts The RJ-45 Ethernet connectors have two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the speed. See T able 3-26.

  • Page 51: Usb Connectors

    CN Type: USB port CN Location: F igure 3-24 CN Pinouts: T able 3-28 The NANO-PV-D4251/N4551/D5251 has four external USB 2.0 ports. The ports connect to both USB 2.0 and USB 1.1 devices. PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA-...

  • Page 52: Vga Connector

    NANO-PV-D4251/N4551/D5251 EPIC SBC 3.3.4 VGA Connector CN Label: VGA1 15-pin Female CN Type: CN Location: See Figure 3-24 CN Pinouts: See Figure 3-27 and Table 3-29 Connects to a monitor that accepts a standard VGA input. Figure 3-27: VGA Connector...

  • Page 53: Installation

    NANO-PV-D4251/N4551/D5251 EPIC SBC Chapter Installation Page 40...

  • Page 54: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-PV-D4251/N4551/D5251. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-PV-D4251/N4551/D5251 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 55: Installation Considerations

    4.2 Installation Considerations NOTE: The following installation notices and installation considerations should be read and understood before the NANO-PV-D4251/N4551/D5251 is installed. All installation notices pertaining to the installation of the NANO-PV-D4251/N4551/D5251 should be strictly adhered to. Failing to adhere to these precautions may lead to severe damage of the NANO-PV-D4251/N4551/D5251 and injury to the person installing the motherboard.

  • Page 56: Unpacking

    NANO-PV-D4251/N4551/D5251 vendor reseller/vendor where the NANO-PV-D4251/N4551/D5251 was purchased or contact an IEI sales representative. 4.4 SO-DIMM Installation SO-DIMM is a critical component of the NANO-PV-D4251/N4551/D5251. If it is not installed the NANO-PV-D4251/N4551/D5251 cannot run. Page 43...

  • Page 57: So-Dimm Installation

    NANO-PV-D4251/N4551/D5251 EPIC SBC 4.4.1 SO-DIMM Installation To install an SO-DIMM, please follow the steps below and refer to Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the board on an anti-static mat. Step 2: Align the SO-DIMM with the socket. Align the notch on the memory with the notch on the memory socket.

  • Page 58: At Auto Button Power Select Jumper Settings

    NANO-PV-D4251/N4551/D5251 EPIC SBC Before the NANO-PV-D4251/N4551/D5251 is installed in the system, the jumpers must be accordance with desired configuration. jumpers NANO-PV-D4251/N4551/D5251 are listed in T able 4-1. Description Type Label AT Auto Button 2-pin header J_AUTOPWR1 Clear CMOS 3-pin header J_CMOS1 CompactFlash®...

  • Page 59: At/Atx Power Select Jumper Settings

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-2: AT Auto Button Select Jumper Settings 4.5.2 AT/ATX Power Select Jumper Settings Jumper Label: J_ATXCTL1 Jumper Type: 3-pin header (1x3) Jumper Settings: See Table 4-3 Jumper Location: See Figure 4-3 The AT/ATX Power Select jumper specifies the systems power mode as AT or ATX.

  • Page 60: Clear Cmos Jumper

    Jumper Location: F igure 4-4 If the NANO-PV-D4251/N4551/D5251 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1 and 2.

  • Page 61: Com 3 Function Select Jumper

    NANO-PV-D4251/N4551/D5251 EPIC SBC The location of the clear CMOS jumper is shown in F igure 4-4 below. Figure 4-4: Clear CMOS Jumper 4.5.4 COM 3 Function Select Jumper Jumper Label: Jumper Type: 6-pin header Jumper Settings: See Table 4-5 Jumper Location:...

  • Page 62: Com 3 Rs-422/485 Function Select Jumper

    NANO-PV-D4251/N4551/D5251 EPIC SBC 4.5.5 COM 3 RS-422/485 Function Select Jumper Jumper Label: 6-pin header Jumper Type: See Table 4-5 Jumper Settings: Jumper Location: See Figure 4-5 The COM 3 Function Select jumper sets the communication protocol used by the second serial communications port (COM 3) as RS-422 or RS-485.

  • Page 63: Compactflash® Voltage Selection

    NANO-PV-D4251/N4551/D5251 EPIC SBC Setting Description Open Slave Closed Master Table 4-7: CompactFlash® Setup Jumper Settings Figure 4-7: CompactFlash® Setup Jumper Location 4.5.7 CompactFlash® Voltage Selection WARNING: Incorrect voltages can destroy the CF card. Make sure to select a voltage that matches the voltage required by the CF card.

  • Page 64: Lvds1 Screen Resolution Selection

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-8: CompactFlash® Voltage Selection Jumper Location 4.5.8 LVDS1 Screen Resolution Selection Jumper Label: J_LCD_TYPE1 Jumper Type: 8-pin header Jumper Settings: See Table 4-9 Jumper Location: See Figure 4-9 The LVDS1 Screen Resolution Selection jumper allows the LVDS screen voltage to be set.

  • Page 65: Lvds Voltage Selection

    NANO-PV-D4251/N4551/D5251 EPIC SBC 4.5.9 LVDS Voltage Selection WARNING: Incorrect voltages can destroy the LCD panel. Make sure to select a voltage that matches the voltage required by the LCD panel. Jumper Label: J_VLVDS1 6-pin header Jumper Type: Jumper Settings: See Table 4-10...

  • Page 66: Chassis Installation

    The NANO-PV-D4251/N4551/D5251 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 67: Motherboard Installation

    4.7 Internal Peripheral Device Connections This section outlines the installation of peripheral devices to the onboard connectors 4.7.1 AT/ATX Power Connection Follow the instructions below to connect the NANO-PV-D4251/N4551/D5251 to an AT or ATX power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-PV-D4251/N4551/D5251.

  • Page 68: Figure 4-12: Power Cable To Motherboard Connection

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-12: Power Cable to Motherboard Connection Step 3: Connect Power Cable to Power Supply. Connect one of the 4-pin (1x4) Molex type power cable connectors to an AT/ATX power supply. See Figure 4-13. Page 55...

  • Page 69: Audio Kit Installation

    Figure 4-13: Connect Power Cable to Power Supply 4.7.2 Audio Kit Installation The Audio Kit that came with the NANO-PV-D4251/N4551/D5251 connects to the audio connector on the NANO-PV-D4251/N4551/D5251. The audio kit consists of three audio jacks. Mic-in connects to a microphone. Line-in provides a stereo line-level input to connect to the output of an audio device.

  • Page 70: Single Rs-232 Cable (W/O Bracket)

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-14: Audio Kit Cable Connection Step 3: Connect the audio devices. Connect speakers to the line-out audio jack. Connect the output of an audio device to the line-in audio jack. Connect a microphone to the mic-in audio jack.

  • Page 71: External Peripheral Interface Connection

    RJ-45 Ethernet cable connector Serial devices USB devices VGA monitor To install these devices, connect the corresponding cable connector from the actual device to the corresponding NANO-PV-D4251/N4551/D5251 external peripheral interface connector making sure the pins are properly aligned. Page 58...

  • Page 72: Lan Connection (Single Connector)

    The dual PS/2 connector is connected to the PS/2 Y-cable that came with the NANO-PV-D4251/N4551/D5251. One of the PS/2 cables is connected to a keyboard and the other to a mouse to the system. Follow the steps below to connect a keyboard and mouse to the NANO-PV-D4251/N4551/D5251.

  • Page 73: Serial Device Connection

    4.8.3 Serial Device Connection The NANO-PV-D4251/N4551/D5251 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the NANO-PV-D4251/N4551/D5251.

  • Page 74: Usb Connection (Dual Connector)

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 1: Locate the DB-9 connector. The location of the DB-9 connector is shown in Chapter 3. Step 2: Insert the serial connector. Insert the DB-9 connector of a serial device into the DB-9 connector on the external peripheral interface. See Figure 4-18.

  • Page 75: Vga Monitor Connection

    Figure 4-19: USB Connector 4.8.5 VGA Monitor Connection The NANO-PV-D4251/N4551/D5251 has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the NANO-PV-D4251/N4551/D5251, please follow the instructions below.

  • Page 76: Software Installation

    Step 0: 4.9 Software Installation All the drivers for the NANO-PV-D4251/N4551/D5251 are on the CD that came with the system. To install the drivers, please follow the steps below. Step 1: Insert the CD into a CD drive connected to the system.

  • Page 77: Figure 4-21: Introduction Screen

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 2: The driver main menu appears (Figure 4-21). Figure 4-21: Introduction Screen Step 3: Click NANO-PV-D4251/N4551/D5251. Step 4: A new screen with a list of available drivers appears (Figure 4-22). Page 64...

  • Page 78: Figure 4-22: Available Drivers

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure 4-22: Available Drivers Step 5: Install all of the necessary drivers in this menu. Page 65...

  • Page 79: Bios Screens

    NANO-PV-D4251/N4551/D5251 EPIC SBC Chapter BIOS Screens Page 66...

  • Page 80: Introduction

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 81: Getting Help

    NANO-PV-D4251/N4551/D5251 EPIC SBC Function F4 key Save all the CMOS changes Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help...

  • Page 82: Main

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 83: Advanced

    NANO-PV-D4251/N4551/D5251 EPIC SBC System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:...

  • Page 84: Trusted Computing

    NANO-PV-D4251/N4551/D5251 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced ACPI Sleep State [S3 (Suspend to R…)] Set the ACPI state used for System suspend ---------------------- : Select Screen ↑ ↓: Select Item Enter Select General Help...

  • Page 85: Cpu Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced TPM Configuration Enables or Disables TPM TPM SUPPORT [Disable] support. O.S. will not show TPM. Reset of Current TPM Status Information platform is required. NO TPM Hardware...

  • Page 86: Bios Menu 5: Cpu Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced CPU Configuration Processor Type Intel(R) Atom(TM) CPU CPU D425 @ 1.80GHz ---------------------- EMT64 Supported Processor Speed 1800 MHz : Select Screen ↑ ↓: Select Item System Bus Speed...

  • Page 87: Sata Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.3.4 SATA Configuration Use the SATA Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PATA Master...

  • Page 88: Usb Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Configure SATA as [IDE] Use the Configure SATA as option to configure SATA devices as normal IDE devices. Configures SATA devices as normal IDE device. EFAULT AHCI Configures SATA devices as AHCI device. 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings.

  • Page 89: Super Io Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded.

  • Page 90: Serial Port N Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port 0 Configuration Enable or Disable Serial...
  • Page 91 NANO-PV-D4251/N4551/D5251 EPIC SBC IO=3F8h; Serial Port I/O port address is 3F8h and the interrupt IRQ=3, 4 address is IRQ3 and IRQ4 Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3 and IRQ4 IRQ=3, 4 IO=2C0h;...
  • Page 92 NANO-PV-D4251/N4551/D5251 EPIC SBC IO=2C8h; Serial Port I/O port address is 2C8h and the interrupt IRQ=3, 4 address is IRQ3 and IRQ4 5.3.6.1.3 Serial Port 2 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.
  • Page 93 NANO-PV-D4251/N4551/D5251 EPIC SBC RS232 Serial Port 2 signaling mode is RS-232 EFAULT Serial Port 2 signaling mode is RS-422/RS-485 RS422/RS485 5.3.6.1.4 Serial Port 3 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.
  • Page 94 NANO-PV-D4251/N4551/D5251 EPIC SBC 5.3.6.1.5 Serial Port 4 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port Enable the serial port Enabled EFAULT Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 95: Irda Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.3.6.2 IrDA Configuration Use the IrDA Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced IrDA Configuration Enable or Disable IrDA IrDA [Enabled] Device Settings IO=2E0h;...

  • Page 96: Parallel Port Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC IO=2C8h; IrDA I/O port address is 2C8h and the interrupt IRQ=10, 11 address is IRQ10, 11 IrDA I/O port address is 2D0h and the interrupt IO=2D0h; address is IRQ10 and IRQ11 IRQ=10, 11 IO=2D8h; IrDA I/O port address is 2D8h and the interrupt...

  • Page 97: H/W Monitor

    NANO-PV-D4251/N4551/D5251 EPIC SBC Change Settings [Auto] Use the Change Settings option to change the parallel port IO port address and interrupt address. Auto The parallel port IO port address and interrupt EFAULT address are automatically detected. Parallel Port I/O port address is 378h and the IO=378h;...

  • Page 98: Bios Menu 12: Hardware Health Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced PC Health Status CPU Temperature :+39 C SYS Temperature :+40 C CPU FAN Speed :4950 RPM VCC3V :+3.312 V V_core :+1.104 V :+4.961 V --------------------- Vcc12 :+11.176 V...

  • Page 99: Serial Port Console Redirection

    NANO-PV-D4251/N4551/D5251 EPIC SBC CPU Smart Fan control [Auto Mode] Use the CPU Smart Fan control option to configure the CPU fan. The fan adjusts its speed using these settings: Auto Mode Temperature Bound 1 Temperature Bound 2 Temperature Bound 3...

  • Page 100: Chipset

    NANO-PV-D4251/N4551/D5251 EPIC SBC Disabled Disabled the console redirection function EFAULT Enabled the console redirection function Enabled 5.4 Chipset Use the Chipset menu (BIOS Menu 14) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 101: Host Bridge Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.4.1 Host Bridge Configuration Use the Host Bridge Configuration menu (BIOS Menu 15) to configure the Northbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset > OnChip VGA Configuration Select which graphics controller to use as the ******* Memory Information ******* primary boot device.

  • Page 102: Onchip Vga Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.4.1.1 OnChip VGA Configuration Use the OnChip VGA Configuration menu (BIOS Menu 15) to configure the OnChip VGA. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset OnChip VGA Configuration Select Share Memory Size. Share Memory Size...

  • Page 103: South Bridge Configuration

    NANO-PV-D4251/N4551/D5251 EPIC SBC Disabled Disabled the multi-monitor function Enabled the multi-monitor function Enabled EFAULT 5.4.2 South Bridge Configuration Use the South Bridge Configuration menu (BIOS Menu 17) to configure the Southbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 104: Intel Igd Swsci Opregion

    NANO-PV-D4251/N4551/D5251 EPIC SBC Enabled USB function support enabled EFAULT USB 2.0 (EHCI) Support [Enabled] Use the USB 2.0 (EHCI) Support BIOS option to enable or disable USB 2.0 support. USB 2.0 (EHCI) support enabled Enabled EFAULT Disabled USB 2.0 (EHCI) support disabled Set Spread Spectrum Function [Disabled] The Set Spread Spectrum Function option can help to improve CPU EMI issues.
  • Page 105 NANO-PV-D4251/N4551/D5251 EPIC SBC DVMT Mode Select [DVMT Mode] Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology (DVMT) operating mode. Fixed A fixed portion of graphics memory is reserved as Mode graphics memory. Graphics memory is dynamically allocated according...

  • Page 106: Boot

    NANO-PV-D4251/N4551/D5251 EPIC SBC 1280x1024 18bit 1366x768 18bit 1280x800 18bit 1280x600 18bit 5.5 Boot Use the Boot menu (BIOS Menu 19) to configure system boot options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...

  • Page 107: Security

    NANO-PV-D4251/N4551/D5251 EPIC SBC Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.

  • Page 108: Bios Menu 20: Security

    NANO-PV-D4251/N4551/D5251 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is...

  • Page 109: Exit

    NANO-PV-D4251/N4551/D5251 EPIC SBC 5.7 Exit Use the Exit menu (BIOS Menu 21) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 110 NANO-PV-D4251/N4551/D5251 EPIC SBC Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 111: Abios Menu Options

    NANO-PV-D4251/N4551/D5251 EPIC SBC Appendix BIOS Menu Options Page 98...
  • Page 112 NANO-PV-D4251/N4551/D5251 EPIC SBC 　 BIOS Information .........................69 　 System Date [xx/xx/xx] ......................69 　 System Time [xx:xx:xx] .......................70 　 ACPI Sleep State [S3 (Suspend to RAM)]................71 　 TPM Support [Disable] ......................72 　 ATA/IDE Configurations [Enhanced] .................74 　 Configure SATA as [IDE].....................75 　...
  • Page 113 NANO-PV-D4251/N4551/D5251 EPIC SBC 　 DVMT/FIXED Memory [256 MB] ..................92 　 IGD - Boot Type [VBIOS Default] ..................92 　 LCD Panel Type [Select by Panel ID] .................92 　 Bootup NumLock State [On]....................93 　 Quiet Boot [Enabled] ......................94 　 Launch PXE OpROM [Disabled] ..................94 　...

  • Page 114: B One Key Recovery

    NANO-PV-D4251/N4551/D5251 EPIC SBC Appendix One Key Recovery Page 101...

  • Page 115: One Key Recovery Introduction

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.

  • Page 116: System Requirement

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.1.1 System Requirement NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. To create the system backup, the main storage device must be split into two partitions (three partitions for Linux).

  • Page 117: Supported Operating System

    NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: Specialized tools are required to change the partition size if the operating system is already installed. B.1.2 Supported Operating System The recovery CD is compatible with both Microsoft Windows and Linux operating system (OS). The supported OS versions are listed below.

  • Page 118: Setup Procedure For Windows

    NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: Installing unsupported OS versions may cause the recovery tool to fail. B.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore Windows system, a few setup procedures are required. Step 1: Hardware and BIOS setup (see Section B.2.1)

  • Page 119: Create Partitions

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 4: Turn on the system. Step 5: Press the <DELETE> key as soon as the system is turned on to enter the BIOS. Step 6: Select the connected optical disk drive as the 1 boot device. (Boot...

  • Page 120: Figure B-3: Recovery Tool Setup Menu

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 3: The recovery tool setup menu is shown as below. Figure B-3: Recovery Tool Setup Menu Step 4: Press <5> then <Enter>. Figure B-4: Command Mode Step 5: The command prompt window appears. Type the following commands (marked in red) to create two partitions.

  • Page 121: Figure B-5: Partition Creation Commands

    NANO-PV-D4251/N4551/D5251 EPIC SBC system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure B-5: Partition Creation Commands Page 108...

  • Page 122: Install Operating System, Drivers And Applications

    NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: Use the following commands to check if the partitions were created successfully. Step 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : B.2.3 Install Operating System, Drivers and Applications...

  • Page 123: Build-Up Recovery Partition

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.2.4 Build-up Recovery Partition Step 1: Put the recover CD in the optical drive. Step 2: Start the system. Step 3: Boot the system from recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be...

  • Page 124: Figure B-8: Build-Up Recovery Partition

    NANO-PV-D4251/N4551/D5251 EPIC SBC recovery files in Section B.2.2 is hidden and the recovery tool is saved in this partition. Figure B-8: Build-up Recovery Partition Step 6: After completing the system configuration, press any key in the following window to reboot the system.

  • Page 125: Create Factory Default Image

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 126: Figure B-12: About Symantec Ghost Window

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-12: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below (Figure B-13). Figure B-13: Symantec Ghost Path Step 5: Select the local source drive (Drive 1) as shown in Figure B-14. Then click OK.

  • Page 127: Figure B-14: Select A Local Source Drive

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-14: Select a Local Source Drive Step 6: Select a source partition (Part 1) from basic drive as shown in Figure B-15. Then click OK. Figure B-15: Select a Source Partition from Basic Drive Step 7: Select 1.2: [Recovery] NTFS drive and enter a file name called...

  • Page 128: Figure B-16: File Name To Copy Image To

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-16: File Name to Copy Image to Step 8: When the Compress Image screen in Figure B-17 prompts, click High to make the image file smaller. Figure B-17: Compress Image Page 115...

  • Page 129: Figure B-18: Image Creation Confirmation

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 9: The Proceed with partition image creation window appears, click Yes to continue. Figure B-18: Image Creation Confirmation Step 10: The Symantec Ghost starts to create the factory default image (Figure B-19). Figure B-19: Image Creation Complete Step 11: When the image creation completes, a screen prompts as shown in Figure B-20.

  • Page 130: Setup Procedure For Linux

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 Setup Procedure for Linux The initial setup procedures for Linux system are mostly the same with the procedure for Microsoft Windows.

  • Page 131: Figure B-22: Partitions For Linux

    NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-22: Partitions for Linux Step 4: Create a recovery partition. Insert the recovery CD into the optical disk drive. Follow Step 1 Step 3 described in Section B.2.2.

  • Page 132: Figure B-23: System Configuration For Linux

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-23: System Configuration for Linux Step 6: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified. In Linux system, enter Administrator (root). When prompt appears, type: cd /boot/grub vi menu.lst...

  • Page 133: Recovery Tool Functions

    NANO-PV-D4251/N4551/D5251 EPIC SBC Step 8: Step 9: The recovery tool menu appears. (Figure B-25) Figure B-25: Recovery Tool Menu Step 10: Create a factory default image. Follow Step 2 Step 12 described in Section B.2.5 to create a factory default image.

  • Page 134: Figure B-26: Recovery Tool Main Menu

    NANO-PV-D4251/N4551/D5251 EPIC SBC Figure B-26: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B.2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 135: Factory Restore

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.4.1 Factory Restore To restore the factory default image, please follow the steps below. Step 1: Type <1> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 136: Backup System

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.4.2 Backup System To backup the system, please follow the steps below. Step 1: Type <2> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 137: Restore Your Last Backup

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 1: Type <3> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).

  • Page 138: Manual

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.4.4 Manual To restore the last system backup, please follow the steps below. Step 1: Type <4> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 139: Other Information

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.5 Other Information B.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 140 NANO-PV-D4251/N4551/D5251 EPIC SBC Step 6: In the following window, select a SATA controller mode used in the system. Then press <Enter>. The user can now start using the SATA HDD. Step 7: After pressing <Enter>, the system will get into the recovery tool setup menu.

  • Page 141: System Memory Requirement

    NANO-PV-D4251/N4551/D5251 EPIC SBC B.5.2 System Memory Requirement To be able to access the recovery tool by pressing <F3> while booting up the system, please make sure to have enough system memory. The minimum memory requirement is listed below. Using Award BIOS: 128 MB system memory Using AMI BIOS: 512 MB system memory.

  • Page 142: C Terminology

    NANO-PV-D4251/N4551/D5251 EPIC SBC Appendix Terminology Page 129...
  • Page 143 NANO-PV-D4251/N4551/D5251 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 144 NANO-PV-D4251/N4551/D5251 EPIC SBC computer is usually a male DE-9 connector. The Digital-to-Analog Converter (DAC) converts digital signals to analog signals. Double Data Rate refers to a data bus transferring data on both the rising and falling edges of the clock signal.
  • Page 145 NANO-PV-D4251/N4551/D5251 EPIC SBC PCIe PCI Express (PCIe) is a communications bus that uses dual data lines for full-duplex (two-way) serial (point-to-point) communications between the SBC components and/or expansion cards and the SBC chipsets. Each line has a 2.5 Gbps data transmission rate and a 250 MBps sustained data transfer rate.
  • Page 146 NANO-PV-D4251/N4551/D5251 EPIC SBC USB 2.0 supports 480Mbps data transfer rates. The Video Graphics Array (VGA) is a graphics display system developed by IBM. Page 133...

  • Page 147: D Watchdog Timer

    NANO-PV-D4251/N4551/D5251 EPIC SBC Appendix Watchdog Timer Page 134...
  • Page 148 NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 149 NANO-PV-D4251/N4551/D5251 EPIC SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30H ;time-out value is 48 seconds ;...

  • Page 150: E Hazardous Materials Disclosure

    NANO-PV-D4251/N4551/D5251 EPIC SBC Appendix Hazardous Materials Disclosure Page 137...

  • Page 151: Hazardous Material Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    NANO-PV-D4251/N4551/D5251 EPIC SBC E.1 Hazardous Material Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 152 NANO-PV-D4251/N4551/D5251 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl Ethers (CR(VI)) (PBB) (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 153 NANO-PV-D4251/N4551/D5251 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

This manual is also suitable for:

Nano-pv-n4551Nano-pv-d5251

Table of Contents
