EPIC SBC with Intel® Atom™ N270 1.6GHz, VGA/LVDS/TTL, Dual GbE,

Quick Installation Guide

Package Contents

NANO-945GSE2 package includes the following items

1 x NANO-945GSE2 Single Board Computer

2 x RS-232 Cable

2 x SATA Cable

1 x PS/2 KB/MS Y Cable

1 x Power Cable

1 x Mini Jumper Pack

1 x Utility CD

1 x QIG(Quick Installation Guide)

CFII, USB, SATA and PC/104+, RoHS

NANO-945GSE2

Version 1.0

Mar. 11, 2009

Need help?

Do you have a question about the NANO-945GSE2 and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology NANO-945GSE2

Page 1: Quick Installation Guide
NANO-945GSE2 Quick Installation Guide Version 1.0 Mar. 11, 2009 Package Contents NANO-945GSE2 package includes the following items 1 x NANO-945GSE2 Single Board Computer 2 x RS-232 Cable 2 x SATA Cable 1 x PS/2 KB/MS Y Cable 1 x Power Cable...
Page 2 Specifications CPU : Intel® Atom™ N270 1.6GHz with a 533MHz FSB System Chipset : Intel® 945GSE+ICH7M BIOS : AMI BIOS System Memory : 1x DDR2 SO-DIMM 400/533MHz support up to 2GB Ethernet : Dual Realtek RTL8111CP GbE (PCIe Interface) I/O Interface : 3 x RS-232 (COM1, COM2, COM4) 1 x RS-232/422/485 (COM3) 6 x USB 2.0 (2 on Rear Side, 4 by pin-header)
Page 3 Humidity : Operation: 5% ~ 95%, non-condensing Dimensions : 165mm x 115mm Weight : GW:700g, NW:350g Ordering Information NANO-945GSE2-N270-R10 : EPIC SBC with Intel® Atom™ N270 1.6GHz, VGA/LVDS/TTL, Dual GbE, CFII, USB, SATA and PC/104+ 32000-070301-RS : Dual Ports USB Cable 32200-000049-RS : RS-232 Cable...
Page 4 Connector /Jumper List LABEL FUNCTION ATXCTL1 Power on mode setting Battery Connector SATA1, SATA2 Power Connectors LCD TTL Interface Connector Main Power Input Connector (option) COM1 External Serial Port Connectors (RS-232) COM2 Internal Serial Port Connectors (RS-232) COM4 Internal Serial Port Connector COM3 (RS-232/422/485,RS-422/485 in JP2) DIMM1...
Page 5 JP3: LVDS Voltage Selection DESCRIPTION 3.3V (default) ATXCTL1: Power Supply Type Selection ATXCTL1 DESCRIPTION Open ATX (default) Short J_CMOS1: Clear CMOS setting J_CMOS1 DESCRIPTION Normal (default) Clear CMOS Setup J3: LPT Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# ALF# ERROR# PAR_INI# SLCTIN#...
Page 6 CN3 : LCD TTL Interface Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC_LCD VCC_LCD VCC_LCD VCC_LCD TFT_B0 TFT_B1 TFT_B2 TFT_B3 TFT_B4 TFT_B5 TFT_B6 TFT_B7 TFT_G0 TFT_G1 TFT_G2 TFT_G3 TFT_G4 TFT_G5 TFT_G6 TFT_G7 TFT_R0 TFT_R1 TFT_R2 TFT_R3 TFT_R4 TFT_R5 TFT_R6 TFT_R7 FPCLK T_VSYNC TFT_EN...
Page 7 J9: Compact Flash Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION PDD3 PDD11 PDD4 PDD12 PDD5 PDD13 PDD6 PDD14 PDD7 PDD15 PDCS#1 PDCS#3 PDIOR# PDIOW# VCC5 IRQ14 VCC5 VCC5 CSEL IDERST# PIORDY PDA2 PDREQ PDA1 PDDACK# PDA0 IDEACTP# PDD0 P66DET PDD1 PDD8 PDD2 PDD9...
Page 8 COM1, COM2, COM3, COM4 : Internal/Externa Serial Port Connectors (RS-232) DESCRIPTION DESCRIPTION DATA CARRIER DATA SET DETECT (DCD#) READY (DSR#) RECEIVE DATA REQUEST TO (RXD) SEND (RTS#) TRANSMIT DATA CLEAR TO SEND (TXD) (CTS#) DATA TERMINAL RING INDICATOR READY (DTR#) (RI#) DIO1: 8-bit GPIO Connector PIN NO.
Page 9 LVDS1 : LVDS Interface Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LVDS_DAP0 LVDS_DAN0 LVDS_DAP1 LVDS_DAN1 LVDS_DAP2 LVDS_DAN2 LVDS_CLKA LVDS_CLKA# LVDS_DBP0 LVDS_DBN0 LVDS_DBP1 LVDS_DBN1 LVDS_DBP2 LVDS_DBN2 LVDS_CLKB LVDS_CLKB# VCC_LCD VCC_LCD VCC_LCD VCC_LCD BT1: Battery Connector IR1 : Infrared Interface PIN NO. DESCRIPTION Connector PIN NO.
Page 10 F_PANEL1 : PWR & RST Button and Indicators panel PIN DESCRIPTI PIN DESCRIPTI PWRBTSW- 2 Power GROUND GROUND SYSRST- RESET -HDLED Ground JP2: COM3 RS-422/485 pin-header PIN NO. DESCRIPTION PIN NO. DESCRIPTION TX_422- RX_422- TX_422+ RX_422+ D_485+ D_485- JP1: Configure COM3 KB/PS1 : MOUSE &...
Page 11 SATA1 & SATA2 : Serial CN1, CN2: SATA1, SATA2 ATA Connectors Power Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) INV1 : 5-pin Header Inverter Connector PIN NO. DESCRIPTION L_BKLTCTL +12V L_BKLTEN J_LCD_TYPE1: LVDS Panel Resolution Selection setting OPEN OPEN OPEN OPEN...
Page 12 PW1: Main Power Input Connector PIN NO. DESCRIPTION Vin(+12V) Vin(+12V) CN5: Main Power Input Connector (option) (Co-layout with PW1) PIN NO. DESCRIPTION Vin(+12V)
Page 13 Board Layout: Connector Locations...
